TDK Corporation ACT1210L2012PTL00 Automotive Common Mode Filter
The ACT1210L-201 series is a compact common mode filter designed for automotive Ethernet and signal lines, especially suited for power train and safety systems. These filters operate within a broad temperature range of -40°C to +125°C and are compliant with AEC-Q200 standards, ensuring high durability and reliability. Featuring a high inductance of 200µH, they enable high-level signal integrity and noise suppression in automotive environments. Their small 3225 size offers easy incorporation into space-constrained designs while maintaining excellent electrical performance for electric vehicle and infotainment applications.
TDK Corporation ACT1210L2012PTL00 Automotive Common Mode Filter Specifications:
- Type: Common mode filter
- Size: 3225 (inch) / 80.8 × 42.8 mm
- Inductance: 200µH ±30/-10% at 100kHz
- Rated Voltage: Up to 80V
- Rated Current: 70mA
- Temperature Range: -40°C to +125°C
- Compliance: AEC-Q200
- Operating frequency: 100kHz
- Construction: Compact, suitable for automotive Ethernet
- Packaging: Reel with 6,000 pcs
- Dimensions: Length 44.0mm, Width 20.3mm, Height 3.9mm
- Material: High-quality magnetic core and copper wire
- Additional features: High noise suppression, high durability in automotive conditions
Buy the Buy EMC Components TDK Common mode filters ACT1210L-201 Online
Enhance your automotive signal and power systems with our high-quality ACT1210L-201 common mode filter. Designed for reliable performance from -40°C to +125°C, it ensures superior noise suppression and durability in challenging environments. Its compact 3225 size allows easy integration into space-constrained designs, while the high inductance of 200µH improves signal integrity. Perfect for automotive Ethernet, infotainment, and powertrain applications, this filter meets strict industry standards, providing dependable operation for modern vehicles. Buy online now and secure reliable performance.
Order your EMC Components Series ACT1210L-201 common mode filter today and enhance the signal integrity of your automotive Ethernet and safety systems.
Frequently Asked Questions
Where can I buy TDK Corporation ACT1210L2012PTL00?
You can click on the BUY or RFQ button to purchase ACT1210L2012PTL00 from an authorized TDK Corporation distributor.
How do I troubleshoot issues or seek technical support for part ACT1210L2012PTL00?
You can download the ACT1210L2012PTL00 datasheet or visit the TDK Corporation website for support.
Who is the manufacturer of ACT1210L2012PTL00?
TDK Corporation
