TDK Corporation CLF5030NIT101MD Automotive Power Inductor
The CLF5030NI-D is a magnetic shield type wound inductor designed for power circuits in automotive electronics, including ECM, airbags, headlights, and electronic power steering. It features a wide temperature range from -55°C to +150°C, with inductance options from 1μH to 470μH in the E-6 series lineup, suitable for high-current applications. The inductor is compatible with lead-free solder, RoHS compliant, halogen-free, and engineered for high reliability, offering optimal performance in automotive and general electronic equipment that demands durability and stable operation under harsh conditions.
TDK Corporation CLF5030NIT101MD Automotive Power Inductor Specifications:
- Inductance Range: 1μH to 470μH (E-6 Series)
- Tolerance: +30% (for lower values), +20% (for higher values)
- Operating Temperature Range: -55°C to +150°C (including self-temperature rise)
- Storage Temperature: -55°C to +150°C
- Package Quantity: 2000 pieces/reel
- Weight: Approximately 0.24 grams per piece
- RoHS Directive Compliant, Halogen-free
- Suitable for automotive applications and general electronics
- Lead-free solder compatibility
- Magnetic shield type wound inductor
- Dimensions (mm): Length 5.7, Width 5.4, Height 1.5±0.1
- Reflow profile recommended: preheating at 150°C for 60-120s, peak temperature 245°C for 8 seconds
- Coil construction: wound ferrite core
- Model: CLF5030NIT-Series, individual part numbers include CLF5030NIT-101M-D, CLF5030NIT-471M-D, etc.
- Application: Automotive ECMs, airbags, headlights, electronic power steering, meters, ABS
- Standards: AEC-Q200 compatible
Buy the Buy TDK CLF5030NI-D Part Number CLF5030NIT101MD Online
Purchase the TDK CLF5030NIT101MD inductor online today for reliable automotive power circuit applications. Designed for high temperature operation from -55°C to +150°C, it features a wide inductance range from 1μH to 470μH, RoHS compliance, and halogen-free construction. Ideal for ECMs, airbags, headlights, and electronic steering systems, this magnetic shield wound inductor ensures durability, stability, and optimal performance in demanding environments. Order now to enhance your electronic assemblies with precision-engineered solutions built for long-lasting reliability.
Get TDK CLF5030NIT101MD today—engineered for high-temperature tolerance and automotive reliability.
Frequently Asked Questions
Where can I buy TDK Corporation CLF5030NIT101MD?
You can click on the BUY or RFQ button to purchase CLF5030NIT101MD from an authorized TDK Corporation distributor.
How do I troubleshoot issues or seek technical support for part CLF5030NIT101MD?
You can download the CLF5030NIT101MD datasheet or visit the TDK Corporation website for support.
Who is the manufacturer of CLF5030NIT101MD?
TDK Corporation
