TDK Corporation SPM3012T4R7MLR Power Inductor
The SPM-LR series 3012 type from TDK consists of commercially rated magnetic shield wire-wound inductors designed for power circuits using a metallic magnetic material. These inductors have inductance values ranging from 0.47 μH to 4.7 μH and feature a low profile design with dimensions of 3.2mm x 3mm x 1.2mm. They offer low resistance, with maximum DCR values from 34.8 mΩ to 266.3 mΩ, and support Isat currents from 2.4A to 7.3A. These inductors maintain low inductance variance in high-temperature environments and provide good DC superimposition characteristics. Their inductance tolerance is ±20%, and they are suitable for reflow soldering. Compared to ferrite wound inductors, they enable large current handling, low resistance, and compact size, making them ideal for various power applications.
TDK Corporation SPM3012T4R7MLR Power Inductor Specifications:
- Inductance: 0.47 μH to 4.7 μH
- Dimensions: 3.2 mm x 3.0 mm x 1.2 mm
- DCR max: 34.8 mΩ to 266.3 mΩ
- Rated current: 2.4A to 7.3A (Isat), 1.6A to 5.0A (Temp)
- Inductance tolerance: ±20%
- Operating temperature range: —40 to +125 °C
- Package quantity: 2000 pcs/reel
- Construction: Wound inductor with magnetic shielding
- Application: Power supplies, VRMs, electronic devices
Buy the TDK Series SPM Power Inductor: SPM3012T4R7MLR
Enhance your electronic projects with the durable and space-efficient magnetic shield inductors from TDK. The SPM-LR series ensures reliable performance across a wide temperature range, supporting high current loads with low resistance. Perfect for power supplies, VRMs, and various compact electronic devices, these inductors provide stability, efficiency, and ease of reflow soldering. Order now and experience the high-quality construction and consistent performance that meet industry standards for professional and hobbyist applications alike.
Get TDK SPM3012T4R7MLR today—built for precision and long-lasting durability in power circuit applications.
Frequently Asked Questions
Where can I buy TDK Corporation SPM3012T4R7MLR?
You can click on the BUY or RFQ button to purchase SPM3012T4R7MLR from an authorized TDK Corporation distributor.
How do I troubleshoot issues or seek technical support for part SPM3012T4R7MLR?
You can download the SPM3012T4R7MLR datasheet or visit the TDK Corporation website for support.
Who is the manufacturer of SPM3012T4R7MLR?
TDK Corporation
