TDK Corporation SPM5015T3R3MLR Power Inductors

The SPM-LR series 5015 type from TDK consists of commercial-grade magnetic shielded wire-wound inductors designed for power circuits, utilizing a metallic magnetic core material. These inductors feature inductance values ranging from 1 µH to 10 µH and are characterized by their low profile dimensions of 5.4mm x 5.1mm x 1.5mm. They offer a maximum DC resistance (DCR) between 24.8 mΩ and 193.8 mΩ, with Isat currents from 2.7A to 8A. The inductors demonstrate minimal inductance variance in high-temperature environments with good DC superimposition. They have an inductance tolerance of ±20% and operate within -40°C to +125°C. Compared to ferrite wound inductors, they enable higher current handling, lower resistance, and compact design. Suitable for reflow soldering.

View SPM5015T3R3MLRDatasheet [pdf]

Buy the TDK Series SPM Inductors: SPM5015T3R3MLR

Buy TDK Series SPM5015T3R3MLR inductors online today and benefit from high current handling, low DCR, and excellent temperature stability. These power inductors feature a magnetic shield design and compact form factor ideal for advanced electronics like tablets, servers, and power modules. Designed for reflow soldering, they ensure reliable performance across a wide temperature range of -40°C to +125°C. Perfect for applications requiring minimal inductance variance and high thermal stability, ensuring your electronic circuits operate efficiently and safely with superior inductance control in compact sizes.

Order your TDK Series SPM5015T3R3MLR inductors today and enhance your power circuits with reliable, low-profile components that deliver high current capacity and superior thermal performance.
