TDK Corporation SPM5030T2R2M Power Inductor
The SPM5030 series is a magnetic shield wound inductor designed for power circuits, utilizing metallic magnetic material for enhanced performance. Offering large current capacity, low Rdc, and compact size, these inductors maintain low inductance variance at high temperatures with excellent DC superimposition characteristics. Featuring an integrated molded coil, they produce less hum noise compared to core adhesive coils. Suitable for PCs, HDDs, servers, VRMs, and compact power supplies, the SPM5030 series ensures reliable operation within temperatures from -40°C to +125°C, making them ideal for demanding electronic applications.
TDK Corporation SPM5030T2R2M Power Inductor Specifications:
- Dimensions: 5.3+0.1 mm (L) x 5.5+0.1 mm (W) x 3.3+0.1 mm (H)
- Operating temperature range: -40°C to +125°C
- Self-temperature rise included
- Material: Metallic magnetic material with integrated molded coil
- Inductance options: 0.20 µH to 47 µH, tolerance ±20%
- Rated current (Isat): 21.0 to 85.0 mA based on model
- DC resistance: 2.31 to 49.5 mΩ depending on model
- Frequency: Measured at 100 kHz
- Package style: Reels, 500 pieces per reel
- Operating temperature: -40°C to +125°C
- Weight: 0.364 g
- Reflow profile: Preheating at 260°C, natural cooling
- Certified: RoHS compliant and suitable for reflow soldering
Buy the Buy Inductors Power Circuits Part Number SPM5030T2R2M Online
Discover the high-quality power inductor SPM5030T2R2M, designed for demanding electronic applications. Featuring metallic magnetic material and integrated molded coil, this inductor delivers low Rdc, high current capacity, and stable performance over a wide temperature range. With a compact size and low noise, it’s ideal for PCs, servers, VRMs, and power supplies that require dependable operation. Purchase online now to ensure your project benefits from proven durability and superior electrical characteristics, ensuring optimal efficiency and safety.
Order your inductors for power circuits SPM5030T2R2M today and enhance your electronic projects with reliable, high-current, low-noise performance.
Frequently Asked Questions
Where can I buy TDK Corporation SPM5030T2R2M?
You can click on the BUY or RFQ button to purchase SPM5030T2R2M from an authorized TDK Corporation distributor.
How do I troubleshoot issues or seek technical support for part SPM5030T2R2M?
You can download the SPM5030T2R2M datasheet or visit the TDK Corporation website for support.
Who is the manufacturer of SPM5030T2R2M?
TDK Corporation
