TDK Corporation VLS5045EX330M Magnetic Shield Inductor
The VLS5045EX series is a high-performance, magnetic shield type wound inductor designed for power circuits in electronic devices such as TVs, STBs, and game consoles. Featuring a ferrite magnetic material, it offers high magnetic shielding, larger current capacity, and low Rdc for enhanced efficiency. Suitable for high-density surface mounting, it complies with RoHS directives, ensuring environmentally friendly use. Its robust construction ensures reliable operation in demanding power applications, and it supports lead-free soldering processes for modern manufacturing standards.
TDK Corporation VLS5045EX330M Magnetic Shield Inductor Specifications:
- Dimensions: 5.0x5.0x4.5 mm
- Inductance: 1.0 µH ±30%
- Temperature Range: -40°C to 105°C
- Operating temperature includes self-temperature rise
- RoHS compliant, halogen-free, lead-free solder compatible
- Rated current: 8.9 A, typical ISAT: 8.9 A, maximum temperature rise: 40°C
- DC Resistance: 0.015 Ω at 100 kHz
- Suitable for high-density mounting with a magnetic shield
- Package quantity: 1500 pieces per reel
- Material: Ferrite magnetic core with wound construction
- Reflow solder profile: preheat at 150°C, peak at 220°C, handle with proper thermal process
- Compliance: RoHS, halogen-free, suitable for lead-free soldering
- Applications: Audio-visual equipment, game devices, power supplies
Buy the Buy TDK VLS5045EX Part Number VLS5045EX330M Online
Purchase your TDK VLS5045EX330M inductors online today for reliable power circuit performance in consumer electronics. These high-current, magnetic shield wound inductors are compliant with RoHS, halogen-free, and support lead-free soldering, ensuring environmentally friendly manufacturing. With optimal size, high inductance, and low resistance, they are ideal for applications in TVs, game consoles, and AV equipment. Ordering online guarantees fast delivery, genuine quality, and technical support, making them the perfect choice for professional electronic device designers and manufacturers.
Order your TDK SeriesVLS5045EX VLS5045EX330M today and give your power circuits reliable, high-current inductors with excellent EMI shielding.
Frequently Asked Questions
Where can I buy TDK Corporation VLS5045EX330M?
You can click on the BUY or RFQ button to purchase VLS5045EX330M from an authorized TDK Corporation distributor.
How do I troubleshoot issues or seek technical support for part VLS5045EX330M?
You can download the VLS5045EX330M datasheet or visit the TDK Corporation website for support.
Who is the manufacturer of VLS5045EX330M?
TDK Corporation
