TDK Corporation VLS5045EX470MH Automotive Power Inductor
The VLS5045EX-H series is a magnetic shield wound inductor designed for high-density automotive power circuits. It features a ferrite magnetic material and optimized core design to support larger currents and lower Rdc. Operating within -40 to +125 °C, this inductor is compliant with AEC-Q200 standards, making it suitable for automotive applications such as ECMs, airbags, headlights, electronic power steering, meters, and ABS systems. Its compact size and robust construction ensure reliable performance in demanding environments, providing effective power management and noise filtering for automotive electronic systems.
TDK Corporation VLS5045EX470MH Automotive Power Inductor Specifications:
- Dimensions: 5.0x5.3x4.5 mm
- Inductance: from 1.0uH to 220uH (various models)
- DC Resistance: from 0.015Ω to 0.73Ω
- Rated Current: up to 8.9A (for 1.0uH model)
- Operating Temperature Range: -40°C to +125°C
- Compliance: AEC-Q200
- Magnetic Shield Type: Ferrite core with shield
- Frequency Characteristics: Up to 10kHz measurement range
- Inductance vs. DC Bias: Shows inductance variation with current
- Package Style: Reels, 1500 pcs per reel
- Dimensions in mm: Length 5.35, Width 5.65, Height 47
- Reflow Soldering: Peak 250°C, Preheat 60-120s, Cooling natural
- Storage Conditions: 5°C to 40°C, 0-75% RH, within 12 months
Buy the Innovative VLS5045EX-H – Reliable Automotive Power Inductors for Industrial Applications
Secure your automotive power applications with the VLS5045EX-H inductors. Designed for automotive ECMs, airbags, and lighting systems, these inductors feature ferrite cores for high current capacity and low resistance. With a compact size and robust construction, they support high-density mounting and reliable operation over a wide temperature range. Easy to integrate into your designs, they are ideal for noise filtering, power management, and ensuring long-lasting performance in extreme conditions. Purchase online now to enhance your automotive electronic projects with dependable inductors.
Order your Keysight VLS5045EX-H series automotive power inductor today and ensure dependable power filtering and noise suppression in demanding vehicle electronic systems.
Frequently Asked Questions
Where can I buy TDK Corporation VLS5045EX470MH?
You can click on the BUY or RFQ button to purchase VLS5045EX470MH from an authorized TDK Corporation distributor.
How do I troubleshoot issues or seek technical support for part VLS5045EX470MH?
You can download the VLS5045EX470MH datasheet or visit the TDK Corporation website for support.
Who is the manufacturer of VLS5045EX470MH?
TDK Corporation
