TDK Corporation VLS6045EX150M Power Inductor
The VLS6045EX series offers high-performance magnetic shield wound inductors ideal for power circuits. Featuring ferrite magnetic materials and optimized core shapes, these inductors support high current with low Rdc, making them suitable for AV devices, gaming, and STB applications. Operating from -40°C to +105°C, they ensure reliable operation under demanding conditions. With various inductance options from 0.47 µH to 680 µH, rated currents up to 14 A, and compact 6.0x6.0x4.5 mm dimensions, these inductors combine durability and high-frequency stability for advanced electronic designs.
TDK Corporation VLS6045EX150M Power Inductor Specifications:
- Dimensions: 6.0x6.0x4.5 mm
- Operating Temperature Range: -40°C to +105°C
- Inductance Range: 0.47 µH to 680 µH
- Rated Current: up to 14 A
- DC Resistance: from 0.010 Ω to 0.47 Ω
- Material: Ferrite magnetic core with magnetic shield
- Tolerance: ±30%, ±20%, ±20% (varies by model)
- Frequency Range: up to 700 kHz for rated inductance measurement, up to 1000 MHz for high-frequency characteristics
- Packaging: Reels of 1500 pieces
- Mounting: Suitable for surface-mount technology (SMT)
- Temperature Rise: Includes self-temperature rise considerations in rated current
- Applications: Power management in AV equipment, gaming consoles, set-top boxes
Buy the Buy Manufacturer VLS6045EX Power Inductor Part Number VLS6045EX150M Online
Enhance your electronic devices with the high-quality VLS6045EX power inductor series. Designed for power circuits, these inductors provide low Rdc, high current capacity, and excellent thermal stability. Perfect for AV, gaming, and set-top box applications, they feature compact size and reliable performance under extreme temperature ranges from -40°C to +105°C. Suitable for surface-mount assembly, these inductors come in various inductance values up to 680 µH, ensuring efficient energy storage and filtering in demanding applications. Order online now for fast delivery and superior quality.
Order your Manufacturer VLS6045EX power inductor VLS6045EX150M today and ensure robust, high-current power management for your electronic projects.
Frequently Asked Questions
Where can I buy TDK Corporation VLS6045EX150M?
You can click on the BUY or RFQ button to purchase VLS6045EX150M from an authorized TDK Corporation distributor.
How do I troubleshoot issues or seek technical support for part VLS6045EX150M?
You can download the VLS6045EX150M datasheet or visit the TDK Corporation website for support.
Who is the manufacturer of VLS6045EX150M?
TDK Corporation
