TDK Corporation VLS6045EX1R0NH Automotive Power Inductor
The VLS6045EX-H series inductors are magnetic shield wound inductors designed for power circuits in automotive applications. They feature high magnetic shield construction with ferrite cores for high-density mounting, larger current capacity, and lower DC resistance. These inductors meet AEC-Q200 standards and are suitable for automotive equipment including ECM, airbags, headlights, and electronic power steering. They are engineered for reliability, with optimized dimensions and performance, ensuring stability and efficiency in high-temperature environments typical of automotive systems. Compact design allows for easy integration into densely populated electronic modules, maintaining high inductance with minimal loss.
TDK Corporation VLS6045EX1R0NH Automotive Power Inductor Specifications:
- Series: VLS-EX-H
- Material: Ferrite magnetic core
- Dimensions: 6.0 x 6.3 mm, height 4.7 mm
- Inductance options: 1.0 to 220 µH with ±30% or ±20% tolerance
- Rated current: up to 82 A (for 15 µH), 58 A (for 47 µH), 34 A (for 150 µH), 8.5 A (for 220 µH)
- DC resistance: varies from 0.012 Ω to 0.47 Ω
- Temperature range: -40°C to +125°C
- Frequency: Measured at 100 kHz
- Compliance: AEC-Q200 automotive standard
- Packaging: Reels of 1500 pcs; soldering profile includes preheating at 250°C, peak reflow at 260°C
Buy the Electronics Series Automotive Power Inductor: VLS6045EX-H
Discover the VLS6045EX-H series inductors, tailored for automotive power circuits with superior magnetic shielding, low resistance, and high-current capacity. Perfect for ECMs, airbags, headlights, and electronic power steering, these inductors ensure dependable operation in high-temperature environments. Their compact design supports high-density mounting, simplifying integration into complex automotive electronic modules. With compliance to AEC-Q200 standards, these inductors offer robustness, stability, and efficiency, making them ideal for demanding automotive applications requiring durability and precision in power management.
Get VLS6045EX-H series inductors today—built for automotive power circuits with high magnetic shielding and reliable performance.
Frequently Asked Questions
Where can I buy TDK Corporation VLS6045EX1R0NH?
You can click on the BUY or RFQ button to purchase VLS6045EX1R0NH from an authorized TDK Corporation distributor.
How do I troubleshoot issues or seek technical support for part VLS6045EX1R0NH?
You can download the VLS6045EX1R0NH datasheet or visit the TDK Corporation website for support.
Who is the manufacturer of VLS6045EX1R0NH?
TDK Corporation
