TDK Corporation VLS6045EX470M Power Inductor
The VLS6045EX series is a high-performance, ferrite-wound inductor designed for power circuits, offering high magnetic shield construction with optimized ferrite cores for higher current capacity and lower Rdc. Operating within -40 to +105°C, it is used in AV, gaming, ON, and STB equipment. Its compact 6.0x6.0x4.5 mm size supports high-density mounting, ensuring reliable magnetic shielding and low losses, suitable for various electronic power management needs, featuring rated currents up to 700 A, and inductance values from 0.47 to 680 µH. Its robust construction and precise specifications make it ideal for demanding power and signal filtering applications.
TDK Corporation VLS6045EX470M Power Inductor Specifications:
- Dimensions: 6.0x6.0x4.5 mm
- Operating temperature range: -40°C to +105°C
- Inductance range: 0.47 µH to 680 µH
- Rated current: up to 700 A
- DC resistance: 0.010 to 0.47 Ω
- Rated frequency: 230%, 220%, 700 kHz
- Material: Ferrite magnetic core with magnetic shield construction
- Packaging: Reel with 1500 pcs
- Storage temperature: -40°C to +105°C
- Soldering profile: Peak temperature 250°C, 40s duration
- Compliance: RoHS, suitable for high-density mounting
- Application: Power supply filters, AV equipment, gaming, STB
Buy the Eaton Series VLS Power Inductor: VLS6045EX470M
Purchase the Eaton VLS6045EX470M power inductor online today to ensure reliable performance in your electronic circuits. Designed for high current capacity and excellent magnetic shielding, this compact component is ideal for power supply filtering, AV equipment, gaming devices, and STB applications. Its robust construction, operating within -40°C to +105°C, guarantees durability and efficient thermal performance. With easy ordering, fast delivery, and the assurance of quality, buy now to enhance your power management solutions instantly.
Get Eaton VLS6045EX470M today—built for precision, high current capacity, and long-lasting durability in power circuits.
Frequently Asked Questions
Where can I buy TDK Corporation VLS6045EX470M?
You can click on the BUY or RFQ button to purchase VLS6045EX470M from an authorized TDK Corporation distributor.
How do I troubleshoot issues or seek technical support for part VLS6045EX470M?
You can download the VLS6045EX470M datasheet or visit the TDK Corporation website for support.
Who is the manufacturer of VLS6045EX470M?
TDK Corporation
