TE CONNECTIVITY 123839420 10 Position PCB Terminal Block
The TE Connectivity 1-2383942-0 is a PCB terminal block designed for secure wire-to-board connections. This header-style block features 10 positions arranged in a single row with a 3.5mm centerline, making it suitable for a variety of applications. It supports wire sizes from 28-16AWG and is rated for a maximum current of 12A and a voltage of 300VAC. The block is constructed with a high-temperature polyamide housing and copper alloy contacts, ensuring durability and reliable performance. It is also side stackable, allowing for increased density in your designs. This component is ideal for power and signal transmission in industrial control panels, automation systems, and other electronic devices.
TE CONNECTIVITY 123839420 10 Position PCB Terminal Block Specifications:
- Wire Protection: With
- Block Type: PCB Mount
- Terminal Block Connector Type: Header
- Connector System: Wire-to-Board
- Connector & Contact Terminates To: Printed Circuit Board
- Threaded Flange: Without
- Stacked Levels: Level 1
- Stacking Configuration: Side Stackable
- Number of Positions: 10
- Number of Rows: 1
- Wire Entry Angle: Side
- Current Rating (Max): 12 A
- Voltage Rating: 300 VAC
- Interlock: Without
- Color: Black
- Contact Mating Area Plating Material: Tin
- Contact Mount: Surface Mount
- Contact Base Material: Copper Alloy
- Contact Current Rating (Max): 12 A
- Screwless Terminal Block: No
- Mounting Angle: Vertical
- Screw Size: M2
- Screw Plating Material: Tin
- Screw Material: Copper Alloy
- Screw Flange: Without
- Connector Mounting Type: Board Mount
- Housing Color: Black
- Housing Material: High Temperature Polyamide
- Centerline (Pitch): 3.5 mm[.13 in]
- Wire Size: .08 – 1.31 mm²
- Operating Temperature Range: -40 – 105 °C[-40 – 221 °F]
- Circuit Application: Power & Signal
- Packaging Method: Tape & Reel
- Packaging Quantity: 300
Buy the 1-2383942-0 TE CONNECTIVITY 10 Position PCB Terminal Block | myMectronic
Purchase the TE Connectivity 1-2383942-0 PCB Terminal Block securely and efficiently for your project needs.
Buy Now
Frequently Asked Questions
Where can I buy TE CONNECTIVITY 123839420?
You can click on the BUY or RFQ button to purchase 123839420 from an authorized TE CONNECTIVITY distributor.
How do I troubleshoot issues or seek technical support for part 123839420?
You can download the 123839420 datasheet or visit the TE CONNECTIVITY website for support.
Who is the manufacturer of 123839420?
TE CONNECTIVITY
