TE CONNECTIVITY 19719031 PV4 Connector
The SolarLok PV4 connector is a weather-proof, IP68 rated connection solution designed for photovoltaic panels. It features a robust housing and tin copper contacts, offering reliable performance in harsh environments. With quick, easy assembly and lower contact resistance, it maximizes power output and conforms to industry standards such as UL and TUV. Suitable for connecting panels to inverters, it supports up to 30 A/40 A at 85°C and a rated voltage of 600 V/1000 V. Its durable construction ensures long-term, secure outdoor PV system connections.
TE CONNECTIVITY 19719031 PV4 Connector Specifications:
- Housing: Durable polymer
- Contact Material: Tin copper
- Protection Degree: IP68 (1 m/24 hr)
- Connector Length: 625 mm
- Connector Width: 24.5 mm
- Diameter: 18.7 mm
- Rated Voltage: 600 V / 1000 V (UL); 1000 V (TUV)
- Electrical Rating: 20 A (UL), 35 A (TUV) for 4 mm2; 30 A (UL), 40 A (TUV) for 6 mm2 at 85°C
- Temperature Rating: -40°C to +105°C
- Standards: UL approved, TUV approved
- Application: Connects PV panels to inverters in solar power systems
Buy the Buy TE Connectivity SolarLok PV4 Connector Part Number 4-173464-8 Online
Enhance your solar power system with the TE Connectivity PV4 Connector. This weather-proof, IP68-rated connector is designed for durability and ease of installation. It features low contact resistance, supporting high current loads up to 40 A, and operates efficiently in harsh outdoor environments. Suitable for connecting PV panels to inverters, it complies with UL and TUV standards, ensuring safety and long-term reliability. Make your solar setup more efficient and secure by purchasing the PV4 connector online today.
Buy TE Connectivity SolarLok PV4 connector now and ensure safe, reliable, and high-efficiency solar panel connections with easy installation and industry-standard performance.
Frequently Asked Questions
Where can I buy TE CONNECTIVITY 19719031?
You can click on the BUY or RFQ button to purchase 19719031 from an authorized TE CONNECTIVITY distributor.
How do I troubleshoot issues or seek technical support for part 19719031?
You can download the 19719031 datasheet or visit the TE CONNECTIVITY website for support.
Who is the manufacturer of 19719031?
TE CONNECTIVITY
