TE CONNECTIVITY 1SNK508960R0000 End Section Dark Grey
The TE CONNECTIVITY ES4-SF end section is a vital accessory for terminal blocks, providing a secure and insulated termination point. Designed for compatibility with fuse holders like ZS4-SF1 and terminal blocks such as ZS4-S-R3, this dark grey component ensures reliable electrical connections. Constructed from polyamide, it offers excellent insulation and durability. With a pollution degree rating of 3 and IP20 protection, it's suitable for various industrial environments. The ES4-SF end section contributes to the overall safety and efficiency of electrical systems by preventing short circuits and providing a clean, organized termination point.
TE CONNECTIVITY 1SNK508960R0000 End Section Dark Grey Specifications:
- Extended Product Type: ES4-SF
- Product ID: 1SNK508960R0000
- EAN: 3472595089604
- Catalog Description: ES4-SF End Section - Dark Grey
- Long Description: Compatible with fuse ZS4-SF1 and disconnect screw clampterminal blocks ZS4-S-R3.
- Minimum Order Quantity: 20 piece
- Customs Tariff Number: 39269097
- Color: Dark Grey
- Product Net Height: 59 mm
- Product Net Length: 59 mm
- Product Net Depth: 31.9 mm
- Product Net Weight: 1.8 g
- Product Net Width: 1.5 mm
- Spacing: 1.5 mm
- Function: End Sections
- Pollution Degree: 3
- Degree of Protection: acc. to IEC 60529, IEC 60947-1, EN 60529 Main Terminals IP20
- Insulation Material: Polyamide
- Suitable For: ZS4-R1, ZS4-SF1, ZS4-SF1-R, ZS4-SF1-T, ZS4-S-R3
- Flammability According to UL94: V0
- Resistance to Vibrations acc. to IEC 60068-2-6: Compliant
- RoHS Status: Following EU Directive 2002/95/EC August 18, 2005 and amendment
- Ambient Air Temperature Operation: -55 ... +110 °C
- Ambient Air Temperature Storage: -55 ... +110 °C
- E-nummer: 2925145
- ETIM 4: EC000886 - Endplate and partition plate for terminal block
- ETIM 5: EC000886 - Endplate and partition plate for terminal block
- ETIM 6: EC000886 - Endplate and partition plate for terminal block
- Object Classification Code: X
- Package Level 1 Width: 158 mm
- Package Level 1 Length: 243 mm
- Package Level 1 Gross Weight: 0.036 kg
- Package Level 1 EAN: 3472595089604
- Package Level 2 Units: 2000 piece
- Product Packing Type: Bag 20 piece
