TE CONNECTIVITY 21088471 GNSS Antenna
The TE Connectivity 2108847-1 is a dual-port GNSS antenna designed for a wide range of applications requiring precise positioning. Featuring a compact form factor (41.0 mm x 41.0 mm x 8.0 mm) and a lightweight design (< 37.0 g), this antenna is suitable for integration into various platforms. It supports L1+G1 & L2+G2 multi bands, providing compatibility with multiple GNSS constellations. The antenna’s specifications, including VSWR (< 1.4:1) and peak gain (typically 3.9 dBic), ensure reliable signal reception. It is ideal for applications such as asset tracking, precision agriculture, and autonomous vehicles.
TE CONNECTIVITY 21088471 GNSS Antenna Specifications:
- Frequency Range (MHz): 1215 - 1250 / 1559 - 1610
- VSWR: < 1.4:1
- Peak Gain at Zenith: Typ. 3.9 dBic / Typ. 2.7 dBic
- Axial ratio at Zenith: Typ. 1.6 dB / Typ. 1.7 dB
- Average Gain: -5.0 dBic / -3.3 dBic
- Isolation: -20 dB / -33dB
- Feed Point Impedance: 50 ohms
- Polarization: RHCP
- Size: 41.0 mm x 41.0 mm x 8.0 mm
- Weight: < 37.0 g
- Mounting: Adhesive Tape
- Operating Temperature: -40 to +85°C
- Storage Temperature: -40 to +85°C
