TE CONNECTIVITY 21089641 ZigBee/Wi-Fi/Bluetooth Antenna
The TE Connectivity 2108964-1 antenna is a compact, dual-band solution engineered for wireless applications such as ZigBee, Wi-Fi, and Bluetooth. Designed for surface mount (SMT) onto printed circuit boards, this antenna offers a convenient and space-efficient integration option. With a frequency range spanning 2400-2500 MHz and 4900-5875 MHz, it caters to a wide range of wireless communication protocols. Its embedded antenna style and linear polarization contribute to reliable signal transmission and reception. The antenna is RoHS compliant and suitable for global applications, making it a versatile choice for various industrial and consumer electronics designs.
TE CONNECTIVITY 21089641 ZigBee/Wi-Fi/Bluetooth Antenna Specifications:
- Wireless Application: Bluetooth, Wi-Fi, ZigBee
- Mounts To: Printed Circuit Board
- Antenna Connection Type: Surface Mount (SMT)
- Application by Region: Bluetooth - Global - 2400 – 2500 MHz, WLAN - Global - 4900 – 5875 MHz
- Antenna Style: Embedded
- VSWR (Max): <2:1
- Impedance: 50 Ω
- Active Antenna: No
- Frequency Band: 2400 – 2500 MHz, 4900 – 5875 MHz
- Gain (Max): 2 dB, 4 dB
- Product Weight: .11 g[.00398 oz]
- Region: Global
- Polarization: Linear
- Product Length: 10 mm[.39 in]
- Product Width: 2.2 mm[.086 in]
- Product Height: 2.5 mm[.098 in]
- Wireless Standard: 802.11 a/b/g/n, Bluetooth & ZigBee
- Packaging Method: Tape & Reel
- Precision Level: Standard
- EU RoHS Directive 2011/65/EU: Compliant
- EU ELV Directive 2000/53/EC: Compliant
- China RoHS 2 Directive MIIT Order No 32, 2016: No Restricted Materials Above Threshold
- Halogen Content: Low Halogen - Br, Cl, F, I < 900 ppm per homogenous material. Also BFR/CFR/PVC Free
