TE CONNECTIVITY 787001100 Aerospace Modular Connector
The Deutsch DMC-MD series are quick-change modular connectors designed for aerospace cabin systems, aircraft IFE, and modern aircraft networks. These connectors offer modularity, easy installation, and high reliability, complying with standards such as EN4165, ARINC 809, and BACC65. They feature lightweight composite housings, thermoplastic modules, and gold-plated contacts for optimal electrical performance. Suitable for high-vibration, high-temperature, and salt spray environments, they support various module configurations, connector types, and panel mounting options, ensuring flexible, robust connections for aerospace applications.
TE CONNECTIVITY 787001100 Aerospace Modular Connector Specifications:
- Housing: Composite, nickel plated
- Modules: Thermoplastic and fluoronated silicone
- Crimp Contacts: Copper alloy, plated gold over nickel
- Temperature Range: -55°C to +175°C
- Vibration: 20 g
- Durability: 500 mating cycles
- Salt Spray Resistance: 500 hours
- Insulation Resistance: 5000 MO
- Contact Current Rating: Sizes vary from 3 A to 46 A
- Interfacial Sealing: 1.1 x 10^7 bar
- Weights: Receptacles approximately 0.013-0.015 lbs, backshells about 0.009-0.020 lbs
- Standards: EN4165, ARINC 809, BACC65
Buy the Buy TE Connectivity DMC-MD Part Number 787001100 Online
Secure your aerospace connectivity needs with the TE Connectivity DMC-MD series. Designed for aircraft cabin systems and IFE, these connectors ensure lightweight, modular, and dependable connections. Compatible with standards like EN4165, ARINC 809, and BACC65, they offer high vibration resistance, salt spray durability, and easy installation. Choose from various module options and panel mounting configurations to customize your aircraft network. Order online now and benefit from fast shipping and expert support for your aerospace projects.
Buy TE Connectivity DMC-MD 787001100 now and experience unmatched reliability and performance in aerospace modular connection systems.
