TE CONNECTIVITY 818792146 High-Precision Thin Film Resistor
The product is a high-precision thin film resistor series designed for accurate and stable performance in various electronic applications. Featuring resistance tolerances as tight as 0.05% and temperature coefficients down to 15ppm/°C, these resistors are available in multiple case sizes from 0201 to 2512. They are suitable for applications requiring close accuracy, stability, and reliable power dissipation. With electroplated matte tin terminal finish and compliance to industry standards, these resistors ensure durability and dependable electrical performance across diverse environments.
TE CONNECTIVITY 818792146 High-Precision Thin Film Resistor Specifications:
- Chip sizes: 0201, 0402, 0603, 0805, 1206, 1210, 2010, 2512
- Rated Power @70°C: 0.03125W (0201), 0.063W (0402, 0603, 0805, 1206), 0.125W (2010), 0.5W (2512)
- Resistance Range: 0Ω to 49.9MΩ (varies by size)
- Tolerance: ±0.05%, ±1%
- Temperature Coefficient (ppm/°C): down to 15ppm/°C for some models
- Maximum Operating Voltage: 15V to 150V depending on size
- Maximum Overload Voltage: 30V to 300V depending on size
- Operating Temp. Range: -55°C to +155°C
- Insulation Resistance: >1000MΩ
- Stability: 0.5%
- Construction: Alumina substrate with NiCr resistor layer, external Sn overcoat
- Derating Curve: Power dissipation decreases at higher ambient temperatures
- Packaging: Reels with quantities from 1000 to 10,000 pcs depending on size
- Environmental compliance: MIL-STD-202 methods for reliability testing
Buy the Connectivity Series CPF: High-Precision Thin Film Resistors 0603 818792146
Enhance your electronic designs with our precision thin film resistors from the Connectivity Series. Offering tight tolerances down to 0.05% and temperature coefficients as low as 15ppm/°C, these resistors are ideal for demanding applications. Available in sizes from 0201 to 2512, they deliver reliable power dissipation up to 0.5W. Perfect for precision circuitry, industrial controls, and communications, order online today and ensure your projects are built with the highest quality resistor components for optimal performance and durability.
Order your Connectivity Series CPF 0603 resistor today and give your electronic projects the dependable accuracy they deserve.
Frequently Asked Questions
Where can I buy TE CONNECTIVITY 818792146?
You can click on the BUY or RFQ button to purchase 818792146 from an authorized TE CONNECTIVITY distributor.
How do I troubleshoot issues or seek technical support for part 818792146?
You can download the 818792146 datasheet or visit the TE CONNECTIVITY website for support.
Who is the manufacturer of 818792146?
TE CONNECTIVITY
