TE CONNECTIVITY T92P11D2212 High Power 12V DC Relay
The T92P11D22-12 is a high-power, general-purpose relay designed for controlling compressor loads in HVAC and industrial applications. It features a dust-protected plastic case, a 2-form-C contact configuration with AgSnOInO contact material, and panel mounting with a flanged cover. The relay has a 12V DC coil with Class-F insulation and can operate up to 155°C coil temperature. It offers vibration resistance of 1.65mm excursions, an insulation resistance of 1 megaohm, and dielectric strength of 1500Vrms between contacts, making it ideal for reliable switching of high-current loads.
TE CONNECTIVITY T92P11D2212 High Power 12V DC Relay Specifications:
- Contact arrangement: 2 form C (2CO)
- Coil Voltage: 12V DC
- Contact Material: AgSnOInO
- Maximum coil temperature: 155°C
- Vibration resistance: 1.65mm excursions at 10-55 Hz
- Dielectric strength: 1500Vrms between open contacts
- Insulation resistance: 1 megaohm between insulated elements
- Clearance: 8mm
- Creepage: 9.5mm
- Initial insulation resistance: 1 megaohm
- Material compliance: RoHS, REACH
- Operating environment: Dust-protected and flux-proof
- Weight: 86g
- Terminal type: Panel mount with flanged cover, quick connect options
- Dimensions: Refer datasheet for detailed measurements
Buy the Buy High Power PCB Relay Part Number T92P11D22-12 Online
Purchase the T92P11D22-12 high-power relay online today and benefit from its robust design, capable of switching high loads up to 30A. Featuring a dust and flux-proof plastic case, 2 form C contacts made of durable AgSnOInO, and a 12V DC coil, this relay is suitable for HVAC, industrial, and commercial applications. Its 155°C max coil temperature, dielectric strength of 1500Vrms, and insulation resistance of 1 megaohm ensure safe and reliable operation. Order now for quick delivery and professional performance.
Buy TE Connectivity T92P11D22-12 relay now and ensure reliable high-current switching with excellent insulation and vibration resistance in industrial controls.
