TE CONNECTIVITY TLM3AER056JTE Current Sense Resistor
This current sensing metal chip resistor from the TLM Series is designed for power electronic systems, offering low resistance, high reliability, and stable thermal coefficient of resistance. Its small form factor ensures optimal power-to-volume ratio, making it ideal for current detection in automotive, industrial, and consumer electronics. Featuring metal foil construction with matte Sn over Ni terminal finish, it withstands high temperatures and overload conditions, ensuring consistent performance in demanding power circuits, with comprehensive electrical and environmental characteristics.
TE CONNECTIVITY TLM3AER056JTE Current Sense Resistor Specifications:
- Power Rating @ 70°C: 0.125W to 1W depending on TLM series model
- Resistance Range: 10mΩ to 100mΩ
- Resistance Tolerance: ±1%, ±2%, ±5%
- Operating Temp. Range: -55°C to +125°C
- Temperature Coefficient of Resistance: ±55°C to +125°C
- Maximum Overload Voltage: 2.5× rated voltage
- Endurance: 1000 hours at max. working voltage, ΔR: 1% max.
- Damp Heat with Load: 1000 hrs at 40°C, 90-95% R.H., ΔR: 1% max.
- Short-term Overload: 5× rated power for 5 sec, ΔR: 0.5%
- Solderability: 95% min. coverage at 245°C for 3 sec
- Construction: Alumina substrate with NiCr electrode layers, resistor alloy layer, epoxy overcoat
- Dimensions for Model TLM3A: Length 6.3mm, Width 2.0mm, Thickness 0.20mm
Buy the TE Connectivity Series TLM Current Sense Resistor: TLM3AER056JTE
Order the TE Connectivity TLM Series current sense resistor online today to ensure reliable current detection in power applications. Designed for high performance with low resistance and stable TCR, this surface-mount component features metal foil construction and matte Sn over Ni terminal finish for durability. Its compact size provides an excellent power-to-volume ratio ideal for automotive, industrial, and consumer electronics. With robust electrical and environmental ratings, it guarantees accurate current sensing, consistent performance, and easy integration into automated assembly processes. Purchase now for optimal reliability in your power systems.
Get TE Connectivity TLM3A today—built for precision and long-lasting durability in power electronic circuits.
Frequently Asked Questions
Where can I buy TE CONNECTIVITY TLM3AER056JTE?
You can click on the BUY or RFQ button to purchase TLM3AER056JTE from an authorized TE CONNECTIVITY distributor.
How do I troubleshoot issues or seek technical support for part TLM3AER056JTE?
You can download the TLM3AER056JTE datasheet or visit the TE CONNECTIVITY website for support.
Who is the manufacturer of TLM3AER056JTE?
TE CONNECTIVITY
