TRACO POWER TDN 3-4811WI Datasheet & Stock

The TDN 3-4811WI from Tracopower is a 3W regulated single output DC to DC converter in DIP package. This DC to DC converter with 4:1 input voltage has fully regulated outputs and remote ON/OFF function. It has continuous, automatic recovery short circuit protection and built-in EN 55022 class A filter. The TDN 3-4811WI has EN 61000-4-2, air ±8KV, contact ±6KV (criteria A) ESD protection and UL 94V-0 rated non conducting FR4 case with UL 94V-0 rated silicone potting and tinned copper pins.




Input voltage range from 18VDC to 75VDC and input current of 13mA at no load

Output voltage of 5VDC and maximum output current of 600mA

Efficiency of 80%

Minimum switching frequency of 100KHz (pulse frequency modulation)

I/O isolation voltage of 1600VDC (60sec)

Greater than 1Gohm I/O isolation resistance and 50pF I/O isolation capacitance

Reflected ripple current of 20mAp-p and maximum surge voltage of 100V

Maximum voltage set accuracy of ±1%

Operating temperature range from -40°C to 70°C without derating

Ultra compact DIP package with 9.1mm x 10.2mm x 13.2mm (W x H x D) dimension





Applications


Power Management,

Industrial
