TRACO POWER TDN34821WI Dual Output Power Converter
The TDN 3-4821WI from Traco Power is a 3W regulated dual output DC-DC converter housed in an ultra-compact DIP package measuring 9.1mm x 10.2mm x 13.2mm. It features a 4:1 input voltage range from 18V to 75V DC, with fully regulated output voltages of ±5V DC and a maximum output current of ±300mA. The converter provides high efficiency of 80%, with a minimum switching frequency of 100 kHz (pulse frequency modulation). It offers excellent electrical isolation capabilities, including an I/O isolation voltage of 1600V DC for 60 seconds, greater than 1 GΩ I/O isolation resistance, and 50 pF I/O isolation capacitance. The device includes remote ON/OFF control, continuous short circuit protection with automatic recovery, and a built-in EN 55022 Class A filter. It meets safety standards such as EN 61000-4-2 (ESD) with ±8kV air and ±6kV contact discharge. The case is constructed from UL 94V-0 rated non-conducting FR4 with UL 94V-0 silicone potting and tinned copper pins for durability. It operates reliably across a temperature range from -40°C to 70°C without derating, making it suitable for power management and industrial applications.
TRACO POWER TDN34821WI Dual Output Power Converter Specifications:
- Input Voltage Range: 18V to 75V DC (4:1 range)
- Output Voltage: ±5V DC
- Maximum Output Current: ±300mA
- Efficiency: 80%
- Switching Frequency: 100 kHz minimum (PWM)
- Isolation Voltage: 1600V DC for 60 seconds
- Isolation Resistance: >1 GΩ
- Isolation Capacitance: 50 pF (typ.)
- Operating Temperature Range: -40°C to +70°C
- Case Material: UL 94V-0 FR4
- Potting Material: Silicone (UL 94V-0)
- Dimensions: 9.1mm x 10.2mm x 13.2mm
- Pin Material: Tinned Copper
- Soldering Temperature: Max 260°C for 10 sec
- Safety Standards: EN 61000-4-2 (ESD), UL 62368-1, UL 60950-1
- Protection Features: Short Circuit, Remote ON/OFF
- RF Noise: EN 55022 Class A filter
Buy the Traco Power TDN34821WI – Reliable Dual Output Power Supply for Industrial Applications
Acquire the Traco Power TDN34821WI online today to benefit from a compact, high-efficiency 3W dual output isolated DC-DC converter designed for industrial power management. Featuring a 4:1 input voltage range from 18V to 75V, it provides regulated ±5V outputs at up to 300mA. The device ensures exceptional electrical isolation with 1600V DC withstand, enhanced EMI filtering, and protection features including short circuit recovery. Its rugged construction, operating from -40°C to +70°C, ensures reliable performance in demanding industrial environments. Perfect for power supply needs requiring high stability, safety, and compliance.
Order your Traco Power TDN34821WI today and ensure your industrial systems have a dependable 3W regulated dual output power solution.
