TRACO POWER TEL102415WI DC/DC Converter
The TEL 10WI series comprises compact 10 Watt isolated DC/DC converters housed in a DIP-16 metal package, designed for space-sensitive applications in industrial electronics, instrumentation, and IT. Offering high efficiency up to 88%, these converters feature an ultra-wide 4:1 input voltage range, internal input filter for EN 55032 class A compliance, and a operating temperature range from -40°C to +88°C. They include protections against short circuits, overcurrent, and under-voltage conditions, ensuring reliable performance in demanding environments. Ideal for low-power, high-density applications requiring robust, efficient power conversion.
TRACO POWER TEL102415WI DC/DC Converter Specifications:
- Power: 10 Watt
- Input Voltage Range: Ultra wide 4:1 (models vary, e.g., 3.3 VDC to 42 VDC, 48-75 VDC)
- Output Voltage: 3.3 VDC, 5.1 VDC, 12 VDC, 15 VDC, 24 VDC (multiple models available)
- Output Current Max: 2700 mA for 3.3 V, 2000 mA for 5.1 V, 833 mA for 12 V, 666 mA for 15 V, 416 mA for 24 V
- Efficiency: Up to 88%
- Operating Temperature Range: -40°C to +88°C
- Isolation Voltage: Input to output 1500 VDC, Input to case 1800 VDC
- Case Material: Aluminium alloy, black anodized coating
- Dimensions: Approximately 16.2 mm x 11.2 mm x 12.2 mm
- Protection: Short circuit, overcurrent (160-195%), under voltage shut-down
- Reliability: MTBF over 2,540,000 hours at +25°C
- Standards: IEC/EN/UL 60950-1, IEC/EN/UL 62368-1
- Soldering Profile: Max 260°C for 10 seconds
Buy the Traco Power Series TEL 10WI DC/DC Converter: TEL102415WI
Discover the compact and efficient Traco Power TEL 10WI series of 10 Watt DC/DC converters, ideal for space-constrained industrial electronics, instrumentation, and IT environments. These converters feature an ultra-wide input voltage range of 4:1, high efficiency up to 88%, and built-in EMC filters for EN 55032 class A compliance. With robust protections including short circuit, overcurrent, and under-voltage shutdown, they ensure reliable operation across temperatures from -40°C to +88°C. Perfect for high-density power management in demanding industrial applications.
Buy Traco Power TEL 10WI now and experience unmatched reliability and efficiency for your low-power industrial projects.
Frequently Asked Questions
Where can I buy TRACO POWER TEL102415WI?
You can click on the BUY or RFQ button to purchase TEL102415WI from an authorized TRACO POWER distributor.
How do I troubleshoot issues or seek technical support for part TEL102415WI?
You can download the TEL102415WI datasheet or visit the TRACO POWER website for support.
Who is the manufacturer of TEL102415WI?
TRACO POWER
