TRACO POWER TEL302411 Industrial Power Converter
The TEL 30 Series is a cost-efficient, isolated 30W DC/DC converter with a shielded metal case, suitable for communication, industrial electronics, and distributed power systems. It features high efficiency, multiple output voltages including 2.5V and 3.3V, and adjustable output options. The series supports input ranges from 18-36V or 36-75V, with protections like overload, overvoltage, and undervoltage shutdown. Operating temperature extends from -40°C to +71°C, ensuring reliable performance in demanding industrial environments. Its compact design with six-side shielding makes it ideal for space-constrained applications requiring robust power solutions.
TRACO POWER TEL302411 Industrial Power Converter Specifications:
- Input Voltage Range: 18-36V or 36-75VDC
- Output Voltages: 2.5V, 3.3V, 5.1V, 12V, 15V with adjustable options
- Output Current: up to 6A depending on model
- Efficiency: Up to 88%
- Operating Temperature: -40°C to +71°C (derating applies above 50°C)
- Isolation Voltage: 1500 VDC (input/output)
- Ripple and Noise: Max 100 mV peak-to-peak
- Protection Features: Overload, overvoltage, undervoltage shutdown, remote On/Off
- Package: Shielded metal case, dimensions approximately 51x25x9.6 mm
- Certification: UL60950-1, IEC/EN 60950-1, RoHS compliant
Buy the Buy TRACOPOWER TEL 30 Series 30 Watt Part Number TEL302411 Online
Purchase the TRACOPOWER TEL 30 Series industrial power converter online today for robust and reliable power delivery. Its 30W high-efficiency design, wide input voltage range, and protection features make it ideal for communication, networking, and industrial electronics. Compact and shielded, it ensures consistent performance across a broad temperature range. With adjustable output voltages and UL safety standards, this converter provides a dependable power source for demanding applications. Order now to benefit from fast delivery and professional support.
Get TRACOPOWER TEL 30 Series 30W converter today—compact, high efficiency and built for demanding industrial environments.
Frequently Asked Questions
Where can I buy TRACO POWER TEL302411?
You can click on the BUY or RFQ button to purchase TEL302411 from an authorized TRACO POWER distributor.
How do I troubleshoot issues or seek technical support for part TEL302411?
You can download the TEL302411 datasheet or visit the TRACO POWER website for support.
Who is the manufacturer of TEL302411?
TRACO POWER
