TRACO POWER TEN502415WI DC/DC Converter Module
The TEN 50WI Series is a compact, high-efficiency DC/DC converter module delivering 50W of power within a small 1" x 2" x 0.4" casing. It features a wide 4:1 input voltage range, adjustable output, and excellent efficiency up to 92%. Designed for space-constrained applications, it offers no minimum load requirement, over-temperature protection, remote On/Off, and high isolation of 1500 VDC. Suitable for industrial, communication, and instrumentation uses, this series ensures reliable performance across a broad temperature range from -40°C to +80°C, with optional heatsink for higher thermal management.
TRACO POWER TEN502415WI DC/DC Converter Module Specifications:
- Power: 50 W
- Input Voltage Range: 18-75 VDC
- Output Voltage: 3.3 VDC to 24 VDC (varies by model)
- Output Current Max: 10 A to 2.08 A (depending on output)
- Efficiency: Up to 92%
- Operating Temperature Range: -40°C to +80°C (with derating to +85°C with heatsink)
- Isolation Voltage: 1500 VDC
- Ripple and Noise: 100-150 mVpk-pk (20 MHz bandwidth)
- Dimensions: 1" x 2" x 0.4"
- Protection: Over-temperature, overload, short circuit
- Remote On/Off: Yes, 3.5 to 12 VDC
- Weight: 34 g
- Certifications: UL, IEC, EN standards, RoHS and Reach compliant
- Switching Frequency: 285 kHz
- Start-up Voltage: 9 VDC (24 V models), 18 VDC (48 V models)
- Humidity: 95% non-condensing
- MTBF: >230,900 hours
Buy the Traco Power Series TEN 50WI 50 Watt: TEN502415WI
Purchase the Traco Power TEN502415WI DC/DC converter online today and ensure your projects benefit from high efficiency, compact size, and reliable performance. This 50W converter features a wide input range, adjustable output voltage, and protective features such as over-temperature and short circuit protection. Perfect for industrial automation, communication systems, and instrumentation where space is limited but performance is critical. Fast delivery and secure online ordering make it easy to upgrade your electronic systems with this cost-effective power solution.
Buy Traco Power TEN502415WI now and experience unmatched reliability, high efficiency, and space-saving design for industrial and communication electronics.
