TRACO POWER THL102411 industrial power converter
The THL 10 series from Tracopower are 10W single and dual output DC/DC converters designed for industrial and communication applications. Encased in a compact 1" x 1" metal shielded case with an isolated baseplate, these converters are pin-to-pin compatible with larger 1" x 2" models. They feature a standard pinout, wide 2:1 input voltage range, and an input filter that meets EN 55022 Class A without external components, simplifying integration. The converters offer high efficiency up to 89%, overcurrent and overvoltage protection, and operate reliably over a temperature range of -40°C to +80°C (up to +85°C with a heatsink). They provide 1500VDC input-output isolation (60 seconds), with resistance exceeding 1000 MΩ and capacitance limited to 2000 pF. Ripple and noise are minimal, and the modules are compliant with UL/cUL 60950-1 and IEC/EN 60950-1 safety standards, backed by a 3-year warranty. Typical applications include instrumentation, distributed power architectures, and various industrial electronics.
TRACO POWER THL102411 industrial power converter Specifications:
- Power Rating: 10 Watt
- Input Voltage Range: 3.3 VDC to 75 VDC, 36-75 VDC for some models
- Output Voltage Options: 3.3 V, 5.1 V, 12 V, 15 V, 5 V, 18-36 V for some models
- Maximum Output Current: 1000 mA to 2500 mA depending on model
- Efficiency: Up to 89%
- Isolation Voltage: 1500 VDC (input/output)
- Isolation Resistance: >1000 MΩ
- Isolation Capacitance: 2000 pF max.
- Operating Temperature Range: -40°C to +80°C, up to +85°C with heatsink
- Case Material: Metal with non-conductive FR4 baseplate
- Dimensions: 1" x 1" x 0.5" (approximate)
- Weight: 15 g
- Soldering Temperature: Max +260°C for 10 seconds
- Compliance: UL/cUL 60950-1, IEC/EN 60950-1, RoHS, Reach
- Switching Frequency: 300 kHz typ.
- Safety Standards: UL, cUL
- Ripple and Noise: 80-100 mVp-p depending on model
- Power Derating: 2.5%/K above +60°C without heatsink, 3.5%/K with heatsink
Buy the TracoPower THL 10 Series – Reliable DC-DC Power Converter for Industrial Applications
Purchase the TracoPower THL 10 series DC/DC converters online today to benefit from high efficiency, wide input voltage range, and robust performance. Designed for industrial, instrumentation, and communication applications, these compact power modules are protected against overcurrent and overvoltage, ensuring reliable operation in harsh environments. With UL/cUL safety certification and a 3-year warranty, these converters are essential components for modern power architectures. Experience fast delivery and expert support by ordering online now and power your projects with confidence and peace of mind.
Order your TracoPower Series THL 10 converter today and ensure your industrial projects receive dependable and efficient power solutions.
Frequently Asked Questions
Where can I buy TRACO POWER THL102411?
You can click on the BUY or RFQ button to purchase THL102411 from an authorized TRACO POWER distributor.
How do I troubleshoot issues or seek technical support for part THL102411?
You can download the THL102411 datasheet or visit the TRACO POWER website for support.
Who is the manufacturer of THL102411?
TRACO POWER
