TRACO POWER THL102423 Industrial Power Converter
The THL 10 series from TracoPower offers reliable 10W DC/DC converters in a compact 1-inch by 1-inch shielded metal case with an isolated baseplate. Featuring a wide 2:1 input voltage range and meeting EN 55022 Class A EMI standards without external components, these converters are suitable for industrial electronics, instrumentation, and communication systems. They operate within -40°C to +80°C, up to +85°C with a heat sink, and include short circuit and overvoltage protection. With maximum efficiencies of 89%, the models provide outputs like 3.3V, 5.1V, 12V, and ±12V, ±15V, with excellent isolation, ripple specs, and UL/cUL safety compliance.
TRACO POWER THL102423 Industrial Power Converter Specifications:
- Power: 10 Watt
- Input Voltage Range: 12VDC, 24VDC, 48VDC with 2:1 wide input range
- Output Voltages: 3.3V, 5.1V, 12V, 15V, ±5V, ±12V, ±15V
- Output Currents: up to 2.5A
- Efficiency: up to 89%
- Isolation Voltage: 1500 VDC for 60 seconds
- Input Current (full load): 12V; 3.3V models: 800 mA, others: 1000 mA; 24V: 400-500 mA; 48V: 200-250 mA
- Operating Temperature: -40°C to +80°C, up to +85°C with heat sink
- Ripple & Noise: 80-100 mVp-p
- Switching Frequency: 300 kHz
- Dimensions: 1" x 1" x 0.4" (approximate)
- Protection: Short circuit, overvoltage
- Standards: UL/cUL 60950-1, IEC/EN 60950-1
- Isolation Resistance: >1000 MOhm at 500VDC
- Weight: 15 g
- Construction: Metal case, epoxy potting, tinned copper pins
- Maximum Case Temperature: +100°C
- Certification: Pending
Buy the Buy TracoPower DC/DC Converter Part Number THL102423 Online
Order the TracoPower THL102423 DC/DC converter online today to ensure a high-quality, efficient power supply for industrial electronics, instrumentation, and communication applications. This dependable 10W converter features a compact design, wide input range, excellent isolation, and protection features that guarantee safe and reliable operation. Designed to meet stringent standards like UL and IEC, it provides stable output voltages such as 3.3V, 5.1V, and 12V with up to 89% efficiency. Purchase now to benefit from fast delivery and technical support.
Buy TracoPower THL102423 now and experience unmatched reliability and high efficiency in industrial power solutions.
Frequently Asked Questions
Where can I buy TRACO POWER THL102423?
You can click on the BUY or RFQ button to purchase THL102423 from an authorized TRACO POWER distributor.
How do I troubleshoot issues or seek technical support for part THL102423?
You can download the THL102423 datasheet or visit the TRACO POWER website for support.
Who is the manufacturer of THL102423?
TRACO POWER
