TRACO POWER THL102423WI DC-DC Converter
The THL 10-2423WI from TracoPower is a 10W DC-DC converter in the THL 10WI series. It features a compact 1" x 1" metal case with an isolated baseplate and an industrial standard pinout, providing a convenient pin-to-pin replacement for larger 1" x 2" models. The converter offers an ultra-wide 4:1 input voltage range from 9VDC to 36VDC (nominal 24VDC) and delivers an output of ±15VDC at up to 330mA with typical efficiency of 87%. It includes comprehensive protections such as remote on/off, short circuit, and overvoltage, making it suitable for industrial electronics, instrumentation, and distributed power architectures. The device complies with safety standards UL/cUL 60950-1 and IEC/EN 60950-1, and operates reliably up to temperatures of +75°C or +85°C with optional heat sinking. It features an input current of 30mA at no load and 500mA at full load, with an input isolation voltage of 1500VDC and I/O isolation resistance greater than 1000 MΩ.
TRACO POWER THL102423WI DC-DC Converter Specifications:
- Power: 10 Watts
- Input Voltage Range: 9VDC to 36VDC (nominal 24VDC)
- Output Voltage: ±15VDC
- Output Current Max: 330mA
- Efficiency: 87%
- Isolation Voltage: 1500 VDC
- Input Current at No Load: 30mA
- Input Current at Full Load: 500mA
- Operating Temperature: Up to +75°C or +85°C with heat sink
- Start-Up Voltage: 9 VDC (±0.5 V), Undervoltage Lockout at 8.5 VDC
- Surge Voltage Max: 50 V for 24 V models
- Ripple & Noise: 60 mVp-p
- Humidity: 95% non-condensing
- Dimensions: 1" x 1" x 0.6"
- Case Material: Metal
- Isolation Resistance: >1000 MΩ
- Soldering Temperature: Max +260°C for 10s
- Standards: UL/cUL 60950-1, IEC/EN 60950-1
Buy the Buy TracoPower DC-DC Converter Part Number THL102423WI Online
Purchase the TracoPower THL 10-2423WI online now to benefit from a compact, high-performance 10W DC-DC converter with ultra-wide input range, excellent efficiency, and comprehensive protections. Its small size and industrial-standard pinout make it easy to integrate into industrial electronics, instrumentation, and communication systems. With UL/cUL safety approval and reliable operation at temperatures up to 85°C with optional heat sinking, this converter provides robust power conversion, ensuring stable and safe operation in demanding environments. Order today to elevate your power architecture.
Buy TracoPower THL102423WI now and experience unmatched reliability and high efficiency for industrial power solutions.
