TRIAD MAGNETICS AEU65240 Power Supply
The AEU65-240 is a reliable, efficient switch-mode power supply designed for industrial and telecommunications applications. It offers a single 24VDC output with an adjustable range from 22.8V to 25.2V, delivering up to 64.8W of power. Features include 86.5% efficiency, short startup and hold-up times, overcurrent and overvoltage protection, and compliance with EMC and safety standards like EN55022 and UL60950-1. Its compact design measures 99 x 75 x 35 mm, suitable for various environments, with a 3-year warranty and MTBF of 250,000 hours.
TRIAD MAGNETICS AEU65240 Power Supply Specifications:
- Input Voltage: 90-264VAC, 127-373VDC
- Input Frequency Range: 47-63Hz
- Input Current: 1.6A@115VAC, 0.8A@230VAC
- Max Inrush Current: 30A@115VAC, 60A@230VAC
- Leakage Current: <2.4mA/240Vac
- Output Voltage: 24.0VDC, adjustable 22.8-25.2V
- Output Current: 0-2.7A
- Output Power: 64.8W
- Ripple & Noise: 200mVp-p
- Load Regulation: 20.5%
- Line Regulation: 20.5%
- Efficiency: 86.5%
- Start-up Time: 1000ms/230VAC, 2000ms/115VAC
- Rise-up Time: 30ms
- Hold-up Time: 24ms/230VAC, 12ms/115VAC
- Over Current Protection: 110-160%, Hiccup mode
- Over Voltage Protection: 27.6-32.4VDC
- Dimensions: 99 x 75 x 35 mm
- Weight: 200g
- Operating Temperature: -20°C to 50°C
- Storage Temperature: -40°C to 85°C
- Vibration: 10-500Hz, 2G
- EMC & Safety Compliance: EN55022, EN61000-3-2, UL60950-1
- Warranty: 3 years
- MTBF: 250,000 hours
Buy the Magnetic Series AEU65-240 Power Supply: 24VDC 64.8W
Purchase the Magnetic Series AEU65-240 power supply online today for your industrial or telecommunications projects. This efficient, compact mains power source provides 24VDC output with adjustable voltage, delivering up to 64.8W. Its high efficiency of 86.5%, comprehensive safety and EMC certifications, and 3-year warranty make it ideal for demanding environments. Easy to install, it features short startup and hold-up times, overcurrent and overvoltage protections, ensuring dependable power regulation, reduced downtime, and long-term reliability for your electronic systems.
Order your Magnetic Series AEU65-240 power supply today and ensure reliable power management for your industrial or telecom systems.
Frequently Asked Questions
Where can I buy TRIAD MAGNETICS AEU65240?
You can click on the BUY or RFQ button to purchase AEU65240 from an authorized TRIAD MAGNETICS distributor.
How do I troubleshoot issues or seek technical support for part AEU65240?
You can download the AEU65240 datasheet or visit the TRIAD MAGNETICS website for support.
Who is the manufacturer of AEU65240?
TRIAD MAGNETICS
