TRIAD MAGNETICS VPT2304350 Power Transformer
This power transformer features toroidal construction for reduced stray fields and increased efficiency, ideal for industrial applications. It offers a maximum power of 1000VA, with series input of 230VAC or parallel input of 115VAC, and provides output voltages of 230VAC CT at 4.35A or 115VAC at 8.70A. Built with Class B insulation, it conforms to international safety standards including UL and CE certifications. The transformer includes mounting hardware and tinned lead wires for easy installation. Its compact, low-profile design minimizes size while maximizing performance in demanding environments.
TRIAD MAGNETICS VPT2304350 Power Transformer Specifications:
- Maximum Power: 1000VA
- Input Voltage: Series: 230VAC, 50/60Hz; Parallel: 115VAC, 50/60Hz
- Output Voltage: Series: 230VAC CT @ 4.35A; Parallel: 115VAC @ 8.70A
- Voltage Regulation: 4% TYP from full load to no load
- Temperature Rise: 50°C TYP
- Hipot: 4000VAC, Primary to Secondary
- Efficiency: 95% TYP at full load
- Construction: Toroidal, Class B insulation
- Dimensions: Dimensions in mm with 3mm added for mounting hardware, weight: 8.2kg
- Mounting: Metal plate, rubber pads, M8 x 80mm bolts, nuts, washers
- Connections: UL 1015 lead wires, 12 inches long, 0.50 inches stripped and tinned
- Winding Connections: Series and parallel configurations, not for independent use
- RoHS Compliance: Meets 2011/65/EU requirements
- Certifications: UL, CE, EN standards, compliant with international safety agencies
Buy the Triad Power Transformer – Reliable Toroidal for Industrial Applications
Enhance your industrial setups with the Triad Series VPT230-4350 power transformer. Designed for demanding environments, it offers 1000VA power, high efficiency, and safety certifications including UL and CE. Its toroidal design minimizes size, reduces stray fields, and increases operational reliability. Easy to install with included mounting hardware and tinned lead wires, this transformer is suitable for various power applications. Buy online now for reliable performance that meets international safety and quality standards, ensuring your projects operate smoothly and efficiently.
Order your Triad Series VPT230-4350 power transformer today and ensure your industrial projects benefit from dependable, high-efficiency performance.
