TRIAD MAGNETICS WSU090130013 Power Supply
The WSU090-1300-13 from Triad Magnetics is a compact wall plug-in power supply designed for reliable operation across a wide input voltage range of 100VAC to 240VAC at 50Hz/60Hz. It provides a stable 9V DC output with a capacity of 1.3A, delivering up to 11.7W of power. The power supply features a durable thermoplastic enclosure, a 6-foot output cord, and is double insulated for enhanced safety. Designed for low noise, high efficiency, and compact size, it is ideal for industrial, control, and power management applications. It also complies with UL, CSA standards, and RoHS directives.
TRIAD MAGNETICS WSU090130013 Power Supply Specifications:
- Input Voltage Range: 100-240VAC, 50-60Hz
- Output Voltage: 9VDC
- Output Current: 1.3A
- Maximum Power: 11.7W
- Efficiency: 82.83%
- Ripple & Noise: 150mVpk-pk Max
- No Load Power: <100mW
- Operating Temperature: 0°C to +40°C
- Storage Temperature: -20°C to 60°C
- Humidity: 5% to 95%, Non-condensing
- Leakage Current: <0.25mA
- Dielectric Strength: 4242VDC for 3 seconds
- Case Type: Thermoplastic Molded Enclosure
- Output Cord: 6 ft, 20 AWG
- Safety Certifications: UL 60950-1, CSA C22.2 No. 60950-1, FCC Class B
- RoHS: Compliant as of 2005
- Over Voltage & Short Circuit Protected
Buy the Buy Triad Power Supply Part Number WSU090130013 Online
Purchase the Triad Power Supply WSU090-1300-13 online today for reliable, safe, and efficient power solutions tailored to industrial and control applications. Featuring a 9V DC output at 1.3A, it offers a maximum power of 11.7W, ensuring stable operation in demanding environments. The durable thermoplastic enclosure, 6-foot output cord, low noise operation, and compliance with UL, CSA, and RoHS standards make it ideal for power management needs. Easy to install, double insulated, and rated for temperatures between 0°C and +40°C, it supports long-term, reliable use.
Get Triad WSU090-1300-13 today—built for dependable power delivery in industrial and control systems with safety and high efficiency.
