TRIAD MAGNETICS WSU0902000R13 Switch Mode Power Supply
The WSU090-2000-R13 from Triad Magnetics is a compact wall plug-in switch mode power supply designed for versatile power applications. It operates over an input voltage range of 100VAC to 240VAC at 50Hz/60Hz, providing a regulated 9VDC output with a maximum current of 2A and power output of up to 18W. The power supply features a thermoplastic molded enclosure that is fully enclosed to prevent tampering, with Level IV and V energy efficiency ratings that meet EIAS 2007 standards. It has a dielectric strength of 4KVDC for 60 seconds and is certified compliant with UL 60950-1 and CSA STD C22.2 No. 60950-1. The device features a 5-foot, 18AWG output cord, a 2.5mm internal diameter and 5.5mm outer diameter output plug, and operates effectively within temperatures from 0°C to +40°C at full load. With its low noise, lightweight design, and heat dissipation features, it is suitable for power management and industrial applications.
TRIAD MAGNETICS WSU0902000R13 Switch Mode Power Supply Specifications:
- Input Voltage range: 100-240VAC, 50-60Hz
- Output Voltage: 9VDC
- Output Current: 2A
- Power Output: Up to 18W
- Efficiency level: Level IV and V, meets EIAS 2007 standards
- Dielectric Strength: 4KVDC for 60 seconds
- Operating Temperature Range: 0°C to +40°C
- Storage Temperature Range: -20°C to 60°C
- Humidity: 5% to 95%, Non-condensing
- Safety Certifications: UL 60950-1, CSA C22.2 No. 60950-1
- Dimensions: Enclosure type: Thermoplastic molded; Output Cord: 18 AWG, 6 ft long; Output Plug: 2.5mm internal diameter, 5.5mm outer diameter
- Leakage Current: <0.25mA at 264VAC
- Overvoltage and short circuit protection: Yes
Buy the Triad Reliable WSU090-2000-R13 for Industrial Applications
Purchase your Triad WSU090-2000-R13 switch mode power supply online today to enjoy a reliable, efficient, and certified power solution. Featuring a compact design, 9VDC output at 2A, UL and CSA safety certifications, and an enclosure that prevents tampering, this power supply is ideal for industrial equipment and power management applications. It operates over a broad input voltage range of 100-240VAC at 50/60Hz, delivering up to 18W of power with a 4KV dielectric strength for durability. Lightweight with low noise, it’s your dependable choice for continuous power needs in demanding environments.
Order your Triad Series WSU090-2000-R13 power supply today and ensure reliable power delivery for your industrial projects with superior efficiency.
