TRIAD MAGNETICS WSU2400500 Power Supply
The WSU240-0500 is a 24V DC, 12W wall plug-in power supply that offers a compact, sealed design for safety and tamper resistance. It provides a stable, regulated output voltage suitable for power management in various industrial and commercial applications. The power supply eliminates internal cooling requirements, reducing noise, size, and weight. It features double insulation, Class-B EMI protection, dielectric isolation of 4kVDC for one minute, and operates efficiently in temperatures from -10°C to 40°C. Its six-foot cord and durable thermoplastic enclosure make it ideal for reliable energy solutions.
TRIAD MAGNETICS WSU2400500 Power Supply Specifications:
- Output Voltage: 24V DC
- Power: 12W
- Input Voltage Range: 100-240VAC, 50/60Hz
- Operating Temperature: -10°C to 40°C
- Enclosure: Thermoplastic molded, compact and sealed
- Protection: Class B EMI, double insulation
- Dielectric Isolation: 4kVDC for 1 minute
- Output Cord: 6 feet, 24 AWG
- Compliance: RoHS, UL Listed
- Connector: Switchcraft 722-series or equivalent
- Approval: Listed, safe tamper-resistant design
Buy the Buy Industry Power Supply Power Management Part Number WSU2400500 Online
Purchase the versatile WSU240-0500 power supply online today for reliable 24V DC output, durable safety features, and a compact sealed design. Ideal for industrial, automation, and energy-management applications, this power supply ensures stable operation within -10°C to 40°C temperature ranges and provides dielectric isolation of 4kVDC for one minute. Its six-foot output cord and thermoplastic enclosure enable easy installation and tamper resistance. Suitable for various power management needs, it offers excellent efficiency, compliance with safety standards, and peace of mind through double insulation and Class-B EMI protection. Buy now for secure, energy-efficient solutions.
Buy Triad Magnetics WSU240-0500 now and experience unmatched reliability and safe power delivery in compact form factors.
