TRIAD MAGNETICS WSU2400500R Power Supply
The power supply is designed for industrial and power management applications, offering reliable 24VDC output with high efficiency, safety certifications, and durable construction. It supports wide voltage input from 90-264VAC and provides stable regulation with minimal ripple. Suitable for demanding environments, it features over-voltage and short-circuit protection, low leakage current, and meets stringent safety and EMI standards including UL, CSA, and FCC. With a 5-year warranty, this component ensures dependable long-term operation in diverse settings, complying with RoHS and DOE level VI efficiency requirements.
TRIAD MAGNETICS WSU2400500R Power Supply Specifications:
- Input Voltage range: 90-264VAC
- Input frequency: 50-60Hz
- Input current: <0.4A(RMS) @ 115VAC
- Max Inrush Current: <60A peak @ 115VAC
- Output Voltage: 24VDC
- Output Current: 0.5A
- Regulation: +5%
- Ripple & Noise: 200mVpk-pk Max
- No load power: <100mW
- Efficiency: 82.96%
- Operating Temperature: 0°C to +40°C
- Storage Temperature: -20°C to 60°C
- Humidity: 5% to 95%
- Leakage Current: <0.25mA (264VAC)
- Dielectric Strength: 4242VDC/3secs.
- Warranty: 5 years
- Case Type: Thermoplastic molded enclosure
- Output Cord: 24 AWG, 6 Ft. Long
- Certifications: UL, CSA, FCC Part 15 Class B, RoHS
- Efficiency Level: DOE Level VI compliant
Buy the Buy Triad Power Supply WSU2400500R Online
Get the Triad Power Supply WSU2400500R online today for dependable performance in industrial environments. This 24VDC power unit features wide voltage input, high efficiency, and comprehensive safety approvals including UL, CSA, and FCC certifications. Its durable thermoplastic enclosure and low leakage current make it ideal for demanding applications. Support for RoHS and DOE Level VI standards ensures environmentally responsible operation. Order online now to secure a reliable power source that guarantees long-term performance and safety for your industrial or power management needs, with fast and secure delivery.
Order your Triad Series WSU2400500R power supply today and ensure reliable, safe power delivery for your industrial projects.
Frequently Asked Questions
Where can I buy TRIAD MAGNETICS WSU2400500R?
You can click on the BUY or RFQ button to purchase WSU2400500R from an authorized TRIAD MAGNETICS distributor.
How do I troubleshoot issues or seek technical support for part WSU2400500R?
You can download the WSU2400500R datasheet or visit the TRIAD MAGNETICS website for support.
Who is the manufacturer of WSU2400500R?
TRIAD MAGNETICS
