TRIAD MAGNETICS WSU2401000 Power Supply
The 24VDC, 24W wall plug-in power supply offers a reliable, compact, and efficient solution for power management needs. Its thermoplastic enclosure prevents tampering and eliminates internal cooling components, reducing noise, size, and weight. The regulated output voltage ensures consistent performance, with an operating temperature range of -10°C to 40°C. It features a 24 AWG output cord, complies with Class-B protection standards, and is double insulated. Dielectric isolation of 4kVDC for one minute enhances safety, making it ideal for controlling and powering electronic devices in various industrial and commercial applications.
TRIAD MAGNETICS WSU2401000 Power Supply Specifications:
- Input Voltage Range: 90-264VAC, 50-60Hz
- Output Voltage: 24VDC
- Output Current: 1A
- Efficiency: 86.20%
- Ripple & Noise: 200mVpk-pk Max
- No load power: <100mW
- Operating Temperature Range: 0°C to +40°C
- Storage Temperature Range: -20°C to 60°C
- Humidity: 5% to 95%, Non-condensing
- Leakage Current: <0.25mA (264VAC)
- Dielectric Strength: 4242VDC for 3 seconds
- Safety Certifications: UL, CSA, FCC Class B
- Protection: Over voltage and short circuit protection
- Case: Thermoplastic mold
- Output Cord: 24 AWG, 6 ft. long
- RoHS Compliant
- Warranty: 5 years
Buy the Buy Triad Power Supply WSU240-1000 Part Number WSU2401000 Online
Purchase the Triad Power Supply WSU240-1000 online today and benefit from its reliable, efficient design. This 24VDC, 24W power supply features a durable thermoplastic enclosure, regulated output, and safety certifications including UL and CSA. Its compact form factor and low-noise operation make it perfect for industrial and electronic applications. With a six-foot output cord, dielectric isolation of 4kVDC, and advanced protection features, this power supply ensures safe, consistent performance under a wide range of environmental conditions. Order now for fast delivery and peace of mind.
Buy Triad Power Supply WSU240-1000 now and experience unmatched reliability and compact design for your power management needs.
Frequently Asked Questions
Where can I buy TRIAD MAGNETICS WSU2401000?
You can click on the BUY or RFQ button to purchase WSU2401000 from an authorized TRIAD MAGNETICS distributor.
How do I troubleshoot issues or seek technical support for part WSU2401000?
You can download the WSU2401000 datasheet or visit the TRIAD MAGNETICS website for support.
Who is the manufacturer of WSU2401000?
TRIAD MAGNETICS
