TTElectronics - Welwyn ASC0402150RFT10 Low Resistance Metal Alloy Resistor
The low resistance metal alloy resistor from the LRMA Series offers a resistance range of 1 to 100 milliohms, suitable for current sensing in power electronics. It operates at high temperatures up to 170°C and is RoHS compliant and halogen-free. Available in various power ratings, sizes, and resistance tolerances, this resistor features low thermal EMF, excellent solvent resistance, and stable performance under cyclic load, humidity, and temperature cycling, making it ideal for high-reliability electrical and electronic applications where precise current measurement is critical.
TTElectronics - Welwyn ASC0402150RFT10 Low Resistance Metal Alloy Resistor Specifications:
- Resistance range: 1 to 100 mΩ
- Power rating @70°C: 1W to 3W depending on size and version
- Overload rating (5s): 5 to 15W depending on size and version
- Resistance tolerance: ±1%, ±5%
- TCR (25 to 125°C): +75 to +275 ppm/°C depending on model
- Operating temperature range: -55°C to 170°C
- Insulation resistance: >100 MΩ
- Element material: Cu-Ni or Mn-Cu alloy
- Coating: Black or green UL94-V0
- Dimensions (mm): Size varies (e.g., 1206, 2512, 0815), length and width specified for each size
- Construction: Copper electrode with nickel and tin plating, low TCR alloy plate
- Solvent Resistance: Resistant to industrial cleaning solvents
- Maximum cyclic load at rated power: 0.3% to 0.5%
- Humidity resistance: 0.15% variation over 1000 hours at 85°C, 85%RH
- Temperature cycling: 0.15% variation over 1000 cycles
- Solder Heat Resistance: 0.3% variation after soldering at 260°C for 20s
- Storage Conditions: 5°C to 35°C, 40–75%RH, shelf life 2 years
- Soldering profile: Pre-heat 150-180°C, peak 250-255°C
Buy the TT Electronics Series LRMA Low Resistance: ASC0402150RFT10
Purchase the TT Electronics LRMA series low resistance resistor online and ensure high accuracy and thermal stability for your power electronics projects. This resistor features resistance values from 1 to 100 milliohms, suitable for current sensing in high-power applications, with excellent thermal stability up to 170°C. RoHS compliant and halogen-free, it provides low thermal EMF, reliable performance under cyclic loading, humidity, and temperature variations. Order now to benefit from fast delivery and industry-leading quality assurance for your electronic needs.
Buy TT Electronics LRMA series low resistance resistor now and experience unmatched reliability and performance in power sensing applications.
Frequently Asked Questions
Where can I buy TTElectronics - Welwyn ASC0402150RFT10?
You can click on the BUY or RFQ button to purchase ASC0402150RFT10 from an authorized TTElectronics - Welwyn distributor.
How do I troubleshoot issues or seek technical support for part ASC0402150RFT10?
You can download the ASC0402150RFT10 datasheet or visit the TTElectronics - Welwyn website for support.
Who is the manufacturer of ASC0402150RFT10?
TTElectronics - Welwyn
