TTElectronics - Welwyn GWCR060322KFT5 Thick-Film Chip Resistor
Green Thick-Film Chip Resistors from the GWCR Series are RoHS-compliant, Pb-free components designed for reliable performance and minimal automotive or industrial circuit resistance. Available in sizes from 01005 to 2512, these resistors feature high alumina substrates, Ruthenium oxide resistance elements, and silver palladium, nickel, and tin plated terminations. They offer a resistance range from 10 ohms to 10 megaohms, with power ratings up to 1 watt, voltage limits up to 250V, and tolerance of ±1%. Suitable for high-density PCB assembly, they resist typical industrial cleaning fluids and meet IEC standards, ensuring durability and precision reliability under varying thermal and electrical conditions.
TTElectronics - Welwyn GWCR060322KFT5 Thick-Film Chip Resistor Specifications:
- Sizes: 01005 to 2512 with dimensions from 0.55 mm to 4.0 mm
- Resistance Range: 10 ohms to 10 megaohms
- Power Rating @ 70°C: up to 1 watt (varies by size)
- Voltage Limits: up to 250 volts
- Resistance Tolerance: ±1%
- Materials: High alumina substrate, Ruthenium oxide resistance element, Silver palladium, Nickel, Tin plated terminations
- Operating Temperature Range: -55°C to 155°C
- Dielectric Withstand Voltage: 100 to 500 volts depending on size
- Insulation Resistance: 2160 ohms
- Marking: 3 or 4 digits; 0603 parts use EIA-96 code; zero-ohm jumpers marked ‘O’
- Solderability: Meets IEC 115-1 standards; Terminations meet IEC 68.2.21
Buy the Buy TT Electronics GWCR Series Resistors Part Number GWCR060322KFT5 Online
Purchase TT Electronics GWCR Series Thick-Film Chip Resistors online for high-performance, RoHS compliant components with wide resistance and size options. These lead-free resistors feature high alumina substrates and Ruthenium oxide elements, ensuring stability under thermal variations. Perfect for PCB assembly, they offer resistance from 10 ohms to 10 megaohms, power ratings up to 1 watt, and voltage limits of 250V. Resistant to industrial cleaning fluids, these durable resistors meet IEC standards for solderability and insulation, making them ideal for reliable electronic and industrial circuit applications.
Get TT Electronics GWCR060322KFT5 today—designed for high reliability, precise resistance, and long-lasting durability in industrial and electronic applications.
Frequently Asked Questions
Where can I buy TTElectronics - Welwyn GWCR060322KFT5?
You can click on the BUY or RFQ button to purchase GWCR060322KFT5 from an authorized TTElectronics - Welwyn distributor.
How do I troubleshoot issues or seek technical support for part GWCR060322KFT5?
You can download the GWCR060322KFT5 datasheet or visit the TTElectronics - Welwyn website for support.
Who is the manufacturer of GWCR060322KFT5?
TTElectronics - Welwyn
