TTElectronics - Welwyn LRMAM1206R007FT5 Low Resistance Resistor
The LRMAM1206R007FT5 is a low resistance, metal alloy resistor designed for high-temperature operation and current sensing in power electronics. This Pb-free component features a resistance value of 7 mQ with 1% tolerance, suitable for use in demanding applications requiring RoHS compliance. It offers excellent stability, low thermal EMF, and is compatible with wave and IR reflow soldering. Its compact size (1206) and robust construction make it ideal for precise, high-power, and high-temperature environments, ensuring reliable performance in industrial and electronic systems.
TTElectronics - Welwyn LRMAM1206R007FT5 Low Resistance Resistor Specifications:
- Resistance Range: 0.5mQ to 500mQ
- Resistance Tolerance: 1%
- TCR (25°C): ppm/°C £50
- Power Rating @70°C: 1W
- Size: 1206
- Maximum Ambient Temperature: -55°C to +170°C
- Insulation Resistance: >100 MΩ
- Material: Cu-Ni/ Mn-Cu alloy
- Marking: Ohmic value indicated on component, e.g., 'ROO2' for 2mQ
- RoHS compliant & halogen free
- Suitable for wave and IR reflow soldering with specific profile
Buy the TT Electronics LRMA1206 R7 – Reliable Resistance for Industrial Applications
Enhance your electronic designs with the TT Electronics LRMA1206R007FT5 low resistance resistor. This highly reliable component offers a resistance value of 7 milliohms with 1% tolerance, suitable for high-temperature environments up to 170°C. Its compact 1206 size ensures easy integration into dense circuit layouts. Ideal for power sensing and industrial applications, it complies with RoHS standards, providing eco-friendly and safe usage. Purchase online today and guarantee your projects deliver consistent, high-quality results with performance you can trust.
Order your TT Electronics SeriesLRMA1206 R7 high-temperature resistor today and ensure your power electronics projects benefit from dependable and precise performance.
Frequently Asked Questions
Where can I buy TTElectronics - Welwyn LRMAM1206R007FT5?
You can click on the BUY or RFQ button to purchase LRMAM1206R007FT5 from an authorized TTElectronics - Welwyn distributor.
How do I troubleshoot issues or seek technical support for part LRMAM1206R007FT5?
You can download the LRMAM1206R007FT5 datasheet or visit the TTElectronics - Welwyn website for support.
Who is the manufacturer of LRMAM1206R007FT5?
TTElectronics - Welwyn
