TTElectronics - Welwyn LRMAP2512R003FT4 Power Resistor
The LRMAP2512R003FT4 is a high-performance low resistance metal alloy resistor designed for precision current sensing in power electronics and industrial applications. It features a resistance of approximately 3 milliohms with a tolerance of ±1%, operates at temperatures from -55°C to 170°C, and offers a robust construction with UL94-V0 coating and nickel-tin plating. Suitable for both wave and IR reflow soldering, this resistor provides high overload capacity and low thermal EMF, making it ideal for reliable, high-power electronic circuits requiring consistent low resistance and durability.
TTElectronics - Welwyn LRMAP2512R003FT4 Power Resistor Specifications:
- Resistance Range: 0.5mΩ to 500mΩ
- Resistance Tolerance: ±1%
- Temperature Rating: -55°C to 170°C
- Power Rating @70°C: 3W (Size 2512, Power version)
- Overload Rating (5s): 15W for size 2512
- Material: Cu-Ni/ Mn-Cu alloy
- Dimensions: Length 6.4mm, Width 3.2mm, Thickness 0.2mm (size 2512)
- Insulation Resistance: >100MΩ
- TCR (25°C to 125°C): ±50 ppm/°C
- Features: RoHS compliant, Halogen-free, Resistance to solvents
- Packaging: Tape & reel, 4000/reel for size 2512
- Mounting: Suitable for surface mount soldering, Pb-free reflow profile
- Operating Voltage: Up to 75V (size 2512)
- Max Load at Rated Power: 15W (size 2512)
Buy the TT Electronics LRMAP2512U– Reliable High Power Resistance for Industrial Applications
Order the TT Electronics LRMAP2512 high power resistor online today. Designed for industrial use, it features a resistance of 3 milliohms, operates at temperatures up to 170°C, and offers excellent overload capacity. Ideal for current sensing in power electronics, this RoHS-compliant resistor ensures durability and consistent performance. Its robust construction withstands high thermal loads, making it perfect for demanding applications in manufacturing, automation, and electronics assembly. Secure your supply now and enhance your circuit reliability with this trusted component.
Get TT Electronics LRMAP2512 today—built for high power capacity and long-lasting durability in demanding electronic circuits.
Frequently Asked Questions
Where can I buy TTElectronics - Welwyn LRMAP2512R003FT4?
You can click on the BUY or RFQ button to purchase LRMAP2512R003FT4 from an authorized TTElectronics - Welwyn distributor.
How do I troubleshoot issues or seek technical support for part LRMAP2512R003FT4?
You can download the LRMAP2512R003FT4 datasheet or visit the TTElectronics - Welwyn website for support.
Who is the manufacturer of LRMAP2512R003FT4?
TTElectronics - Welwyn
