TTElectronics - Welwyn LRMAP2512R057FT4 Low Resistance Metal Alloy Resistor
The LRMAP series are low resistance metal alloy resistors designed for high precision current sensing in power electronics. Available in various sizes including 0612, 0805, 1206, 2010, 2512, and 1225, these resistors feature resistance ranges from 0.5mΩ to 500mΩ, with high stability and low thermal EMF versions for reduced noise. They operate up to 170°C, are RoHS compliant, halogen-free, and meet AEC-Q200 qualification. Suitable for high power and low resistance applications, these resistors provide reliable performance in demanding electronic systems.
TTElectronics - Welwyn LRMAP2512R057FT4 Low Resistance Metal Alloy Resistor Specifications:
- Resistance range: 0.5mΩ to 500mΩ
- Maximum operating temperature: 170°C
- Resistance tolerance: ±0.5%, ±1.0%, ±5%
- Resistance values: standard series include 5, 6, 10, 15, 20, 25, 50, 100, 250, 500 mΩ
- Power rating at 70°C: 1W (0805), 2W (0612), 3W (2512), 2W (2512 power type)
- Overload rating (5s): up to 15W depending on size
- Element alloys: Cu-Ni, Mn-Cu for low thermal EMF, Cu-Ni/Mn-Cu for standard models
- Size options: 0805, 1206, 0612, 0815, 2010, 2512, 1225
- Operating ambient temperature: -55°C to 170°C
- Insulation resistance: >100 MΩ
- Marking: ohmic values with codes like ROO2 for 2mΩ
- RoHS compliant and halogen-free, suitable for wave and reflow soldering
- Package options include tape and reel for automated assembly
Buy the Buy Electronics Low Resistance Metal Alloy Resistor Part Number LRMAP2512R057FT4 Online
Enhance your electronic designs with our high-quality low resistance metal alloy resistors. Featuring resistance values from 0.5mΩ to 500mΩ, these resistors are ideal for current sensing in power electronics, offering excellent stability and low thermal EMF. With sizes including 0805, 1206, and 2512, they are RoHS compliant, halogen-free, and qualified for demanding industrial applications. Easy to integrate with tape and reel packaging for automated assembly, ensuring reliable performance under high temperature conditions up to 170°C. Perfect for engineers seeking precision and durability.
Buy Electronics Low Resistance Metal Alloy Resistor LRMAP2512R057FT4 now and experience reliable high-precision current sensing for power electronics.
Frequently Asked Questions
Where can I buy TTElectronics - Welwyn LRMAP2512R057FT4?
You can click on the BUY or RFQ button to purchase LRMAP2512R057FT4 from an authorized TTElectronics - Welwyn distributor.
How do I troubleshoot issues or seek technical support for part LRMAP2512R057FT4?
You can download the LRMAP2512R057FT4 datasheet or visit the TTElectronics - Welwyn website for support.
Who is the manufacturer of LRMAP2512R057FT4?
TTElectronics - Welwyn
