TTElectronics - Welwyn ULR15SR002FT2 Current Sense Resistor
The ULR series current sense resistor features robust metal strip construction capable of withstanding high temperatures and currents. It offers low TCR and inductance, with resistance ranges from 0.15 mΩ to 22 mΩ. These RoHS-compliant, AEC-Q200 qualified devices are available in various sizes including 1206 and 2010, with different coating options such as black, green, and uncoated. Suitable for high power and thermal applications, they are designed for wave or reflow soldering and provide excellent performance in demanding electronic circuits.
TTElectronics - Welwyn ULR15SR002FT2 Current Sense Resistor Specifications:
- Resistance Range: 0.15 mΩ to 22 mΩ
- Sizes: 1206, 2010, 2512
- Coatings: Black, Green, Uncoated
- Power Rating: Up to 0.2 W (depending on size)
- Temperature Coefficient: Low TCR
- Compliance: RoHS, AEC-Q200
- Solderability: >95% coverage (MIL-STD 202F / 208H, 235°C 2 secs)
- Construction: Low TCR alloy with tin-plated connections
- Marking: 4-character IEC62 code for milliohm values
- Operating Temperature: -55°C to +170°C
Buy the TT Electronics ULR15SR002FT2 – Reliable Current Sense Resistor for Industrial Applications
Purchase the TT Electronics ULR15SR002FT2 current sense resistor online today and benefit from its robust construction, precise resistance, and high temperature tolerance. Perfect for industrial and high power applications, this resistor features low TCR and inductance, RoHS compliance, and reliable solderability. Its various sizes and coatings allow flexible integration into your electronic designs. Experience quick delivery and factory-direct pricing while ensuring your circuits maintain accuracy and durability under demanding conditions.
Buy TT Electronics ULR15SR002FT2 current sense resistor now and ensure precision and high thermal stability for your power management needs.
Frequently Asked Questions
Where can I buy TTElectronics - Welwyn ULR15SR002FT2?
You can click on the BUY or RFQ button to purchase ULR15SR002FT2 from an authorized TTElectronics - Welwyn distributor.
How do I troubleshoot issues or seek technical support for part ULR15SR002FT2?
You can download the ULR15SR002FT2 datasheet or visit the TTElectronics - Welwyn website for support.
Who is the manufacturer of ULR15SR002FT2?
TTElectronics - Welwyn
