TTElectronics - Welwyn ULR1SR007FT2 Current Sense Resistor
The ULR series surface mount metal strip current sense resistors are designed for precise current sensing in power electronic systems. These resistors feature low TCR and low inductance, with solid metal elements capable of withstanding high current surges. They come with various coatings including black, green, and uncoated options, suitable for reflow or wave soldering. The resistors are RoHS compliant, AEC-Q200 qualified for automotive environments, and marked clearly with resistance values using IEC62 codes. Physical dimensions and resistance values are optimized for demanding power and measurement applications.
TTElectronics - Welwyn ULR1SR007FT2 Current Sense Resistor Specifications:
- Resistance range: RO005 (0.5mΩ) to RO15 (15mΩ)
- Surface mount style available in 1206, 2512, 2010 sizes
- Low TCR: 50 ppm/°C
- Resistance tolerance: 1%, 5%
- Ambient temperature range: -55°C to +170°C
- Material: Low TCR alloy with tin-plated or protective coatings
- Soldering: Suitable for reflow and wave soldering
- RoHS compliant, AEC-Q200 qualified for automotive use
- Dimensions vary by size; 2512, 1206, 2010
- Marking: IEC62 codes for resistance values
- Protection: Black, green, and uncoated options available
- Resistance markings: 4-character IEC62 codes for integer values, using 'M' for decimals
- Packaging: Reels of 2000 pieces for automated assembly
- Measuring points: 4-wire and 2-wire layouts specified
- Body resistance values: 0.5mΩ to 15mΩ; package resistance approximately between 1.55 to 3.54 mm depending on size
Buy the Buy TT Electronics ULR Series Surface Mount Current Sense Resistors Part Number ULR1SR007FT2 Online
Purchase TT Electronics ULR series surface mount current sense resistors online for precise current measurement in power electronic circuits. These resistors feature low TCR, high surge capability, and RoHS compliance. Available in 1206, 2512, and 2010 sizes with resistance values from 0.5mΩ to 15mΩ. Suitable for automotive and industrial applications, they offer excellent solderability and durability. Buy now to enhance your electronic systems with reliable, automotive-qualified sensing components designed for demanding environments and long-lasting performance.
Get TT Electronics ULR1SR007FT2 today—built for high power sensing with low TCR and RoHS compliance.
Frequently Asked Questions
Where can I buy TTElectronics - Welwyn ULR1SR007FT2?
You can click on the BUY or RFQ button to purchase ULR1SR007FT2 from an authorized TTElectronics - Welwyn distributor.
How do I troubleshoot issues or seek technical support for part ULR1SR007FT2?
You can download the ULR1SR007FT2 datasheet or visit the TTElectronics - Welwyn website for support.
Who is the manufacturer of ULR1SR007FT2?
TTElectronics - Welwyn
