TTElectronics - Welwyn WCR120622KFI Surface-Mounted Resistors
High-reliability surface-mounted resistors designed for general purpose electronic applications, offering a wide range of sizes and ohmic values. Incorporating wrap-around terminations and inner electrode protection, these resistors meet industrial standards such as IEC 115-1 and IEC 68.2.21 for solderability and strength, and are compliant with RoHS3 directives. They feature a high alumina substrate with ruthenium oxide resistance elements, silver palladium and nickel barrier terminations, and glazed protection coating. Suitable for use in harsh environments with broad temperature ranges from -55°C to 155°C, offering excellent performance and durability.
TTElectronics - Welwyn WCR120622KFI Surface-Mounted Resistors Specifications:
- Resistance Range: <50Ω to 10MΩ
- Resistance Tolerance: ±1%, ±2%, ±5%
- TCR: -400 to +600ppm/°C for low ohmic values; +200 to +300ppm/°C for high values
- Ambient Temperature Range: -55°C to 155°C
- Construction: High alumina substrate (96% min), ruthenium oxide resistor element
- Terminations: Silver palladium, nickel barrier, tin plated
- Solderability: Meets IEC 115-1, Clause 4.17.3.2
- Strength: Complies with IEC 68.2.21
- Packaging: Tape mounted on reels, 8mm, 12mm, or 12mm plastic tape depending on size
- Marking: 3 digits indicating resistance value, plus tolerance code, with special marking for jumpers
- Performance: 1000 hours load at 70°C AR% <2, Shelf life 12 months, short-term overload AR% <2
Buy the TT Electronics WCR1206 Series Resistors for Industrial Use
Order TT Electronics surface-mounted resistors online today for reliable performance across industrial applications. These resistors feature a robust alumina substrate, wrap-around terminations, and compliance with RoHS standards, ensuring high durability in harsh conditions. Available in various sizes, ohmic values, and tolerances, they are suitable for demanding environments requiring precise resistance and thermal stability. Purchase now to benefit from fast delivery, quality assurance, and technical support to enhance your electronic designs or manufacturing processes.
Buy TT Electronics WCR1206 resistors now and experience unmatched reliability and performance for demanding industrial environments.
Frequently Asked Questions
Where can I buy TTElectronics - Welwyn WCR120622KFI?
You can click on the BUY or RFQ button to purchase WCR120622KFI from an authorized TTElectronics - Welwyn distributor.
How do I troubleshoot issues or seek technical support for part WCR120622KFI?
You can download the WCR120622KFI datasheet or visit the TTElectronics - Welwyn website for support.
Who is the manufacturer of WCR120622KFI?
TTElectronics - Welwyn
