Taiyo Yuden EKSKBNZWB Bluetooth Low Energy Module
This high-performance Bluetooth 5.0 low energy module features the nRF52840 chip, supporting data rates up to 2 Mbps and operating within 2402 to 2480 MHz. It offers a maximum output power of +8dBm and is powered by a single supply voltage from 1.7V to 5.5V, enabling versatile use in IoT, wearables, and industrial applications. Equipped with ARM Cortex M4F processor, 1MB flash, 256KB RAM, and ARM TrustZone cryptographic security, it provides multiple interface options including USB, UART, SPI, and I2C. Its compact outline is 10.0 x 15.4 x 2.0 mm. The module is qualified for Bluetooth®, FCC, IC, and Japan regulations, suitable for smart home, healthcare, and industrial IoT solutions.
Taiyo Yuden EKSKBNZWB Bluetooth Low Energy Module Specifications:
- Frequency Range: 2402 to 2480 MHz
- Output Power: +8dBm
- Power Supply: 1.7V to 5.5V
- Data Rates: 2M / 1M / 500kbps / 125kbps
- Chip: nRF52840 (Nordic)
- Processor: ARM Cortex M4F 32bit
- Flash Memory: 1MB
- RAM: 256KB
- Operating Temperature: -40°C to 85°C
- Dimensions: 10.0 x 15.4 x 2.0 mm
- Protocols Supported: Bluetooth 5.0, IEEE 802.15.4
- Interfaces: USB, NFC-A, SPI, UART, I2C, I2S, PDM, 12-bit ADC
- Qualified for: Bluetooth, FCC, IC, Japan
- Features: Integrated system, sleep clock, high-performance PCB antenna, cryptographic accelerator
Buy the TAIYO YUDEN EYSKBNZWB – Reliable Bluetooth 5 Low Energy Module for Industrial Applications
Discover the versatility and reliability of the Bluetooth Low Energy module featuring the Nordic nRF52840 chip. With support for Bluetooth 5.0, data rates up to 2 Mbps, and advanced security features including ARM TrustZone cryptographic capabilities, this compact module is ideal for IoT, wearables, smart home devices, and industrial automation. It operates on a single supply voltage between 1.7V and 5.5V, providing flexible power options. Certified for Bluetooth®, FCC, and other standards, it ensures seamless and secure wireless communication in a variety of applications.
Order your TAIYO YUDEN Series EYSKBNZWB Bluetooth module today and enhance your IoT projects with dependable, secure wireless connectivity.
Frequently Asked Questions
Where can I buy Taiyo Yuden EKSKBNZWB?
You can click on the BUY or RFQ button to purchase EKSKBNZWB from an authorized Taiyo Yuden distributor.
How do I troubleshoot issues or seek technical support for part EKSKBNZWB?
You can download the EKSKBNZWB datasheet or visit the Taiyo Yuden website for support.
Who is the manufacturer of EKSKBNZWB?
Taiyo Yuden
