Taiyo Yuden LP12352R7206 Electric Double Layer Capacitor
The LP12352R7206 is a high-voltage electric double-layer capacitor designed for reliable energy storage with a capacitance of 20F and tolerance of ±20%. It operates within a wide temperature range from -40°C to +85°C and withstands a maximum voltage of 2.7V, which reduces to 2.3V above 70°C. The capacitor features low ESR under 40mΩ at 1kHz, excellent charge/discharge cycle durability of 10,000 cycles, and robust humidity and thermal resistance. It is halogen-free, RoHS, and REACH compliant, suitable for various applications requiring precise, stable energy delivery.
Taiyo Yuden LP12352R7206 Electric Double Layer Capacitor Specifications:
- Capacitance: 20F ±20%
- Maximum Voltage: 2.7V (reduces to 2.3V above 70°C)
- Operating Temperature Range: -40°C to +85°C
- Initial ESR (at 1kHz): Under 40mΩ
- Capacitance after 40°C at 2.3V: Over 85% of initial
- Charge/Discharge Cycles: 10,000 times at 2.7V-1.5V, 2A
- Humidity Durability: 95% Rh for 500 hours
- Soldering Method: Solder iron and wave soldering
- Physical Dimensions: Length 35.0mm, Width 12.5mm, Thickness 0.6mm
- RoHS, REACH, Halogen-free: Yes
- Operating temperature also tested up to +85°C
- Initial capacitance and ESR are within initial spec after soldering exposure
- Floating charge for 1000 hours at 2.3V shows capacitance over 70% of initial
- Leak current within specified limits
Buy the Buy TAIYO YUDEN Electric Double Layer Capacitor Part Number LP12352R7206 Online
Experience exceptional energy storage with the TAIYO YUDEN Electric Double Layer Capacitor. Featuring 20F capacitance, wide -40°C to +85°C temperature range, low ESR, and robust cycle life of 10,000 cycles, this halogen-free component is ideal for high-reliability applications. Its compact size, high voltage tolerance, and excellent thermal and humidity resistance ensure optimal performance. Perfect for powering devices that require stable, long-term energy sourcing, it guarantees durability, safety, and compliance with RoHS and REACH standards—order online today for fast delivery.
Get TAIYO YUDEN LP12352R7206 today—built for precision and long-lasting durability in energy storage applications.
Frequently Asked Questions
Where can I buy Taiyo Yuden LP12352R7206?
You can click on the BUY or RFQ button to purchase LP12352R7206 from an authorized Taiyo Yuden distributor.
How do I troubleshoot issues or seek technical support for part LP12352R7206?
You can download the LP12352R7206 datasheet or visit the Taiyo Yuden website for support.
Who is the manufacturer of LP12352R7206?
Taiyo Yuden
