Turck C10A10FX024VDC Industrial Change-over Relay
The C10-A10FX024VDC relay is a single-pole, change-over contact relay rated for 10A at 250V AC1 and 0.5A at 110V DC1, suitable for various switching applications. It features AgNi contact materials and options for gold and tin alloys, ensuring reliable electrical performance. With a max switching voltage of 250V, it supports AC loads up to 2.5 KVA and DC loads to meet diverse industrial needs. The relay includes coil options with low operating voltage, LED indicators, and protective suppressors. Designed for high durability, it boasts a mechanical life of 10 million operations, electrical life of 2.1 million operations, and excellent insulation properties with dielectric strength up to 5 kV. Compact, lightweight, and IP40 rated, it’s optimal for automation systems and control panels.
Turck C10A10FX024VDC Industrial Change-over Relay Specifications:
- Contact Material: AgNi (Standard), options include AgNi + Au, AgSnOz
- Max. Switching Current: 10A
- Max. Peak Inrush Current: 30A (20 ms)
- Max. Switching Voltage: 250V
- AC Load Capacity: 2.5 KVA
- DC Load Capacity: Corresponds to Table 2 specifications
- Dielectric Strength: 1,000 V open contacts, 5 KV between contact and coil
- Insulation Resistance: 21 GΩ at 500 V
- Operate Time + Bounce Time: 10 ms
- Release Time + Bounce Time: 5 ms
- Ambient Temperature Range: -40°C to +70°C
- Mechanical Life: 10 million operations
- Electrical Life at Nominal Load: 2.1 million operations
- Operating Frequency at Nominal Load: 1,200 cycles/hour
- Protection Grade: IP 40
- Dimensions (approximate): 35.4 mm length, 24 mm width
- Coil Voltage Options: 12V, 24V, 48V, 110V, 230V DC
- Optional Features: LED indicators, RC suppressor, diode, bridge rectifier
Buy the Buy Turck C10-A10FX024VDC Part Number C10A10FX024VDC Online
Purchase the Turck change-over relay C10-A10FX024VDC online today to enhance your automation system with a reliable, high-capacity switching component. This single-pole relay features AgNi contacts, supporting 10A at 250V AC and 0.5A at 110V DC, making it perfect for diverse industrial applications. Its robust construction offers a mechanical life of 10 million operations and electrical longevity with 2.1 million. Compact and lightweight, it comes with advanced options such as LED indicators and suppressors, ensuring high performance and durability in control panels and automation setups.
Order your Turck SeriesC10-A10FX024VDC relay today and ensure reliable switching performance for your automation projects.
Frequently Asked Questions
Where can I buy Turck C10A10FX024VDC?
You can click on the BUY or RFQ button to purchase C10A10FX024VDC from an authorized Turck distributor.
How do I troubleshoot issues or seek technical support for part C10A10FX024VDC?
You can download the C10A10FX024VDC datasheet or visit the Turck website for support.
Who is the manufacturer of C10A10FX024VDC?
Turck
