VIGORTRONIX VTX214010105 Industrial Power Supply
This 10 Watt AC-DC power supply features a regulated single output with an adjustable voltage range from 3.3V to 48V DC. It is designed with safety and efficiency in mind, offering low ripple and noise, encapsulated construction, and fully isolated primary and secondary circuits with over 4,200 Vrms insulation. Suitable for various industrial applications, it operates over a wide input voltage range of 90-265 VAC or 100-370 VDC, with low standby power consumption under 0.3W. It complies with international safety and EMI standards, ensuring reliable performance in demanding environments.
VIGORTRONIX VTX214010105 Industrial Power Supply Specifications:
- Power: 10W
- Input Voltage Range: 90 - 265VAC / 100 - 370VDC
- Input Frequency: 47 - 63Hz
- Output Voltage Range: 3.3V to 48VDC (other voltages available on request)
- Output Current: 210mA to 3000mA depending on voltage
- Efficiency: >75%
- Ripple & Noise: <50mV Max
- Standby Power: <0.3W
- Isolation Voltage: >4200Vrms (primary-secondary)
- Operating Temperature: -25°C to +70°C
- Storage Temperature: -40°C to +105°C
- Safety Certifications: EN60950-1, EN61558-1, EN61558-2-6, TUV
- EMC Compliance: EN55022 Class B, EN55024, EN55014-1
- Dimensions: approx. 48mm x 25mm x 25mm
- Weight: 85g
- Additional Features: Low ripple & noise, encapsulated design, optional PCB mounting kit
Buy the Buy Vigortronix Power Supply Part Number VTX214010105 Online
Purchase the Vigortronix industrial power supply online today to ensure reliable, safe, and efficient power for your equipment. Featuring a regulated 3.3V to 48V output, wide input voltage compatibility, low standby power, and high safety standards, it is designed for demanding environments. The compact encapsulated design facilitates easy installation, and its compliance with international safety and EMI standards guarantees dependable operation. Invest in quality, long-lasting power solutions to enhance your industrial automation and control systems.
Get Vigortronix VTX214010105 today—built for precision, safety, and long-lasting durability in industrial power applications.
Frequently Asked Questions
Where can I buy VIGORTRONIX VTX214010105?
You can click on the BUY or RFQ button to purchase VTX214010105 from an authorized VIGORTRONIX distributor.
How do I troubleshoot issues or seek technical support for part VTX214010105?
You can download the VTX214010105 datasheet or visit the VIGORTRONIX website for support.
Who is the manufacturer of VTX214010105?
VIGORTRONIX
