Vishay F182K43S3NN63J5R Ceramic Capacitor
This ceramic disc capacitor features high reliability, low losses, and high capacitance in a small size, suitable for low-loss circuits, SMPS, HF ballast, and high voltage applications. Designed with a ceramic dielectric Y5R/Class 2, it handles voltages up to 2000 Vdc with a capacitance range of 100 pF to 4700 pF. Encapsulated in epoxy resin for flammability resistance, it has kinked leads, specific spacing, and is RoHS compliant, making it ideal for high voltage, snubber, and electronic circuit applications.
Vishay F182K43S3NN63J5R Ceramic Capacitor Specifications:
- Capacitance Range: 100 pF to 4700 pF
- Rated Voltage: 2000 Vdc
- Dielectric: Y5R (Class 2)
- Capacitance Tolerance: +10 %; +20 %
- Temperature Range: -30 °C to +125 °C
- Insulation Resistance: 210000 MΩ at 500 Vdc min.
- Dissipation Factor: Max. 0.2 %
- Lead Diameter: 0.6 mm
- Lead Spacing: 5.0 mm or 7.5 mm
- Encapsulation: Epoxy resin, UL 94 V-0 flammability resistant
- Mounting: Radial, kinked leads
- Marking: Capacitance value and voltage in accordance with EIA 198
- RoHS Compliant
Buy the Vishay Series F Ceramic Capacitor: 2000 Vdc, 4700 pF, F182K43S3NN63J5R
Order the Vishay F182K43S3NN63J5R ceramic capacitor online today and benefit from high voltage tolerance, compact design, high reliability, and excellent performance. Perfect for snubber, high voltage, and electronic circuit applications, this RoHS-compliant capacitor ensures durability in demanding environments with epoxy resin encapsulation. Its precise specifications guarantee quality and efficiency, making it an essential component for engineers and electronic enthusiasts seeking dependable circuit performance with easy online access for quick delivery and optimal project results.
Buy Vishay F182K43S3NN63J5R now and experience unmatched reliability and performance in high voltage electronic circuit applications.
Frequently Asked Questions
Where can I buy Vishay F182K43S3NN63J5R?
You can click on the BUY or RFQ button to purchase F182K43S3NN63J5R from an authorized Vishay distributor.
How do I troubleshoot issues or seek technical support for part F182K43S3NN63J5R?
You can download the F182K43S3NN63J5R datasheet or visit the Vishay website for support.
Who is the manufacturer of F182K43S3NN63J5R?
Vishay
