Vishay MDP1603470RGD04 Resistor Network Module
The Vishay Dale MDP1603470RG molded resistor network offers reliable dual and isolated resistor configurations suitable for various industrial and electronic applications. Configured with high-temperature tolerance, low temperature coefficient, and RoHS compliance, these resistor networks provide consistent performance for power supply, signal processing, and impedance balancing tasks. Constructed with rugged molded epoxy bodies and solder-plated leads, they feature multiple resistance values ranging from 10 Ω to 2.2 MΩ, with precise, stable electrical characteristics. Ideal for automated insertion and long-term durability in demanding environments.
Vishay MDP1603470RGD04 Resistor Network Module Specifications:
- Package Power Rating (Maximum at +70 °C): 1.73 W for MDP14, 1.92 W for MDP16
- Operating Temperature Range: -55°C to +125°C
- Storage Temperature Range: -55°C to +150°C
- Dielectric Strength: 200 V
- Insulation Resistance: ≥ 10,000 MΩ
- Body Material: Molded epoxy
- Lead Material: Solder plated leads
- Dimensions: MDP14 - 0.750 inches (19.05 mm) x 0.600 inches (15.24 mm); MDP16 - 0.850 inches (21.59 mm) x 0.700 inches (17.78 mm)
- Resistance Range: 10 Ω to 2.2 MΩ
- Temperature Coefficient of Resistance: < 50 ppm/°C typical
- Shock Resistance: 100 g's for 18 shocks
- Vibration Resistance: 20 g's for 12 hours
- Solderability: Meets MIL-STD-202, method 208E
- Relates to RoHS compliance, halogen-free options available, and leads suitable for automatic insertion.
Buy the Vishay MDP1603470RG – Reliable Resistor Networks for Industrial Applications
Enhance your electronic designs with the Vishay resistor network module, MDP1603470RG, providing stable dual and isolated resistor configurations. Designed for industrial, commercial, and consumer electronics, this RoHS-compliant device features a rugged molded epoxy body, solder-plated leads, and a broad resistance range from 10 Ω to 2.2 MΩ. With excellent temperature stability, dielectric strength, and high insulation resistance, it ensures reliable operation in demanding environments. Easily integrate into automated assembly lines, reduce assembly costs, and achieve high precision and durability in your applications by ordering online today.
Order your Vishay series MDP1603470RG resistor network today and enhance your electronic projects with dependable, rugged performance and wide resistance options.
Frequently Asked Questions
Where can I buy Vishay MDP1603470RGD04?
You can click on the BUY or RFQ button to purchase MDP1603470RGD04 from an authorized Vishay distributor.
How do I troubleshoot issues or seek technical support for part MDP1603470RGD04?
You can download the MDP1603470RGD04 datasheet or visit the Vishay website for support.
Who is the manufacturer of MDP1603470RGD04?
Vishay
