Vishay MKP1841222204 High-Voltage Polypropylene Capacitor
These high-voltage metallized polypropylene film capacitors are designed for protection circuits in power supplies, snubbers, and electronic ballasts. Capable of handling voltages up to 2000 Vdc and up to 700 Vac, they feature internal series construction with metallized electrodes and a flame-retardant plastic case. Suitable for high pulse and high current operations, their compact dimensions and robust design ensure reliable performance in demanding electronic applications. Compliant with RoHS standards and rated for up to 100°C operating temperature, they are essential for reliable circuit protection and filtering.
Vishay MKP1841222204 High-Voltage Polypropylene Capacitor Specifications:
- Capacitance range: 470 pF to 6.8 μF
- Rated DC voltage: 250 Vdc to 2000 Vdc
- Rated AC voltage: 160 Vac to 700 Vac
- Maximum application temperature: 100°C
- Dielectric: Polypropylene film
- Construction: Internal series construction, metallized electrodes
- Case material: Flame-retardant plastic, UL class 94 V-0
- Leads: Tinned wire
- Compliance: RoHS compliant
- Climatic testing: EN 60068-1 55/100/56
- Marking: C-value, tolerance, rated voltage, manufacturer data
Buy the Vishay Series MKP1841 High-Voltage Polypropylene Capacitor: 2200pF
Order the Vishay MKP1841 high-voltage polypropylene film capacitor online today to ensure high performance and reliable circuit protection. With ratings up to 2000 Vdc and 700 Vac, these capacitors are ideal for high pulse and high current operations. Their flame-retardant epoxy resin sealed case, robust internal series construction, and metallized electrodes guarantee durability in demanding applications. Perfect for snubber circuits, power supplies, and electronic ballasts, buying online guarantees quick delivery and industry-leading quality for your electrical projects.
Buy Vishay MKP1841 high-voltage polypropylene film capacitor now and experience unmatched reliability and performance in power circuits, snubber applications, and electronic ballasts with robust construction and high pulse handling capabilities.
Frequently Asked Questions
Where can I buy Vishay MKP1841222204?
You can click on the BUY or RFQ button to purchase MKP1841222204 from an authorized Vishay distributor.
How do I troubleshoot issues or seek technical support for part MKP1841222204?
You can download the MKP1841222204 datasheet or visit the Vishay website for support.
Who is the manufacturer of MKP1841222204?
Vishay
