Vishay AC05AT0005600JAC00 High Power Wirewound Resistors
Vishay Draloric AC series cemented leaded wirewound resistors are designed for high power, high current applications, including automotive electronics, energy meters, and power supplies. Featuring a robust silicon cement coating resistant to challenging environmental conditions and cleaning solvents, these resistors are built on a ceramic Al2O3 body offering high mechanical resistance, thermal shock, dielectric strength, and insulation at elevated temperatures. With various lead forms, they ensure reliable electrical performance, marked with resistance, dissipation, and tolerance, and are carefully tested for quality and durability, making them ideal for demanding industrial and automotive uses.
Vishay AC05AT0005600JAC00 High Power Wirewound Resistors Specifications:
- Resistance Range: 0.10 Ω to 27 kΩ
- Rated Dissipation: 1W to 10W depending on model
- Maximum Operating Temperature: 250°C
- Material: Ceramic Al2O3, silicon cement lacquer coating
- Lead Styles: Radial taped, Kinked (single and double), WSZ (small & large pitch)
- Lead Diameter: 0.8 mm (FeCu wire)
- Dimensions: Length 11.0 mm to 44.0 mm, Diameter 2 mm to 3 mm, varies by model
- Operating Temp. Range: -55°C to +250°C
- Compliance: RoHS, IEC 62474, GADSL, SVHC compliant
- Test Conditions: IEC 60115-1, IEC 60068-2-xx weather and thermal tests
- Marking: Resistance, power dissipation, tolerance
- RoHS & REACH compliant: No Banned Substances
- Certification: Automotive AEC-Q200 qualified
- Encapsulation: Silicon cement lacquer coating for environmental resistance
Buy the Vishay AC Series – Reliable High Power Wirewound Resistors for Industrial Applications
Order Vishay AC series high power wirewound resistors online today and ensure reliable performance in your industrial or automotive project. Designed with a ceramic Al2O3 base and resistant cement coating, these resistors withstand high temperatures, thermal shocks, and challenging environmental conditions. Available in multiple lead forms like radial taped, kinked, and WSZ for flexible mounting options. Certified for automotive safety standards and RoHS compliant, they offer precise resistance, great pulse load capabilities, and exceptional durability. Make your purchase now for high-quality, resilient resistive solutions tailored for demanding applications.
Buy Vishay AC series high power resistors now and experience unmatched reliability and durability in demanding industrial and automotive environments.
Frequently Asked Questions
Where can I buy Vishay AC05AT0005600JAC00?
You can click on the BUY or RFQ button to purchase AC05AT0005600JAC00 from an authorized Vishay distributor.
How do I troubleshoot issues or seek technical support for part AC05AT0005600JAC00?
You can download the AC05AT0005600JAC00 datasheet or visit the Vishay website for support.
Who is the manufacturer of AC05AT0005600JAC00?
Vishay
